Autonics PSAN-1CPA-RC1/8 Pressure Sensor
The Autonics PSAN-1CPA-RC1/8 Pressure Sensor offers Standard pressure type, 0 to 1,000kPa pressure range, 12-24VDC power supply, Connector type(connector type cable: 2m) connection type , Rc1/8 pressure port. Manufactured by Autonics under the Autonics Pressure Sensor category, this model belongs to the Autonics PSAN Series.
| Brand | Autonics |
| Product Type | Pressure Sensor |
| Model Number | PSAN-1CPA-RC1/8 |
Autonics PSAN-1CPA-RC1/8 Pressure Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
| Pressure type | Standard pressure |
| Rated pressure range | 0 to 1,000kPa |
| Protection structure | IP40 |
| Pressure port | Rc1/8 |
| Power supply | 12-24VDC |
| Current consumption | Voltage output type: Max. 50mACurrent output type: Max. 75mA |
| Pressure port direction | Rear fitting |
| Connection type | Connector type(connector type cable: 2m) |
| Display pressure unit | MPa, kPa, kgf/cmΒ², bar, psi |
| Option input/output | Current output(DC4-20mA) |
| Control output_Hysteresis | Min. display interval |
| Control output_Repeat error | Β±0.2% F.S. Β±Min. display interval |
| Control output_Response time | Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms |
| Control output | PNP open collector |
| Environment_Ambient temperature | -10 to 50β, storage: -20 to 60β |
| Environment_Ambient humidity | 30 to 80% RH, storage: 30 to 80% RH |
| Material | Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass |
| Weight | Approx. 165g(approx. 80g) |
Autonics Pressure Sensors like the PSAN-1CPA-RC1/8 Digital Display Sensor deliver precise air and gas measurement, ensuring reliable performance in automation systems.
The Autonics PSAN-1CPA-RC1/8 Pressure Sensor is engineered to measure pneumatic pressure with high accuracy and stability. Designed for air and non-corrosive gases, it offers a rated range of 0 to 1,000kPa, making it suitable for both standard and high-pressure applications. Powered by a reliable 12β24VDC supply, the sensor integrates seamlessly with PLCs and control panels. It provides PNP open collector output and an additional DC4β20mA current output option, giving engineers flexibility in system integration. Response times are selectable between 2.5ms to 1000ms, allowing customization for fast or stable detection requirements. Its digital display supports multiple units (MPa, kPa, bar, psi, kgf/cmΒ²), helping engineers read pressure in their preferred standard. Built with a nickel-plated brass pressure port (Rc1/8) and a durable polycarbonate housing, it maintains reliability even under continuous industrial use. With IP40 protection and operating range from -10Β°C to 50Β°C, the PSAN-1CPA-RC1/8 balances precision and resilience for everyday factory environments.
In real-world use, the Autonics PSAN-1CPA-RC1/8 Digital Display Pressure Sensor is widely applied in pneumatic systems, compressor monitoring, packaging machinery, and robotic automation. Its ability to respond quickly within 1ms makes it ideal for high-speed lines, while the selectable response settings allow engineers to optimize for either fast switching or stable readings. Maintenance engineers benefit from the compact connector type interface with a 2m cable, which simplifies installation and reduces wiring issues. The multi-unit digital display helps technicians avoid conversion errors, improving accuracy during troubleshooting. Students and junior engineers appreciate its clear interface for training purposes, while senior professionals value its reliability in long-term industrial deployment. With proven trust in Indian factories and global automation systems, the Autonics PSAN-1CPA-RC1/8 Pressure Sensor ensures dependable measurement and control across diverse industries. For further details and related models, visit the official Autonics Pressure Sensors page or the full Autonics Sensors & Controllers range.
