Autonics PSAN-1CA-RC1/8 Pressure Sensor
The Autonics PSAN-1CA-RC1/8 Pressure Sensor offers Standard pressure type, 0 to 1,000kPa pressure range, 12-24VDC power supply, Connector type(connector type cable: 2m) connection type , Rc1/8 pressure port. Manufactured by Autonics under the Autonics Pressure Sensor category, this model belongs to the Autonics PSAN Series.
| Brand | Autonics |
| Product Type | Pressure Sensor |
| Model Number | PSAN-1CA-RC1/8 |
Autonics PSAN-1CA-RC1/8 Pressure Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
| Pressure type | Standard pressure |
| Rated pressure range | 0 to 1,000kPa |
| Protection structure | IP40 |
| Pressure port | Rc1/8 |
| Power supply | 12-24VDC |
| Current consumption | Voltage output type: Max. 50mACurrent output type: Max. 75mA |
| Pressure port direction | Rear fitting |
| Connection type | Connector type(connector type cable: 2m) |
| Display pressure unit | MPa, kPa, kgf/cmยฒ, bar, psi |
| Option input/output | Current output(DC4-20mA) |
| Control output_Hysteresis | Min. display interval |
| Control output_Repeat error | ยฑ0.2% F.S. ยฑMin. display interval |
| Control output_Response time | Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms |
| Control output | NPN open collector |
| Environment_Ambient temperature | -10 to 50โ, storage: -20 to 60โ |
| Environment_Ambient humidity | 30 to 80% RH, storage: 30 to 80% RH |
| Material | Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass |
| Weight | Approx. 165g(approx. 80g) |
The Autonics designed the PSAN-1CA-RC1/8 to deliver precision in Digital Display Pressure Sensor applications. With a standard pressure range of 0 to 1,000 kPa, it supports units like MPa, kPa, kgf/cmยฒ, bar, and psi, making it versatile for various industrial environments.
This Autonics Digital Display Pressure Sensor features an Rc1/8 pressure port, rear fitting connection, and operates on 12โ24VDC power. Selectable response times from 2.5ms to 1000ms, along with current output (DC4โ20mA) and NPN open collector, allow smooth integration with PLCs and control systems.
Built with a polycarbonate housing and nickel-plated brass port, the PSAN-1CA-RC1/8 offers IP40 protection and reliable operation from -10 to 50ยฐC. Learn more at Autonics Sensors & Controllers or the full Autonics Pressure Sensor range.
The Autonics PSAN-1CA-RC1/8 is widely used in pneumatic systems, air compressor monitoring, robotics, and process control. It ensures precise pressure regulation for actuators, cylinders, and automation equipment. Maintenance teams value its fast setup and stable readings, while educators use it to teach industrial pressure measurement and signal control.
