Autonics PRW12-4DP Proximity Sensor
The Autonics PRW12-4DP Proximity Sensor features a 4mm sensing distance, PNP Normally Open output, and DC 3-wire 12β24VDC operation offering consistent performance and high reliability in automation systems. Manufactured by Autonics under the Autonics Proximity Sensors range, this model belongs to the Autonics PR Series. It comes with a M12 sensing side diameter, Max. 10% hysteresis, and 12Γ12Γ1mm iron standard sensing target. Built with IP67 protection (IEC standard) and a 500Hz response frequency, it ensures durability and precise detection in industrial automation applications.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRW12-4DP |
Autonics PRW12-4DP Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 4mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 12Γ12Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-flush |
| Cable Standard/material | Standard connector |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 500Hz |
| Weight | Approx. 54g(approx. 42g) |
Ask for the Pricing of Cylindrical Inductive Proximity Sensors PRW12-4DP at unbeatable prices. Detailed Specifications of PRW12-4DP features the key specifications include a sensing distance of 4mm designed for a standard target of 12Γ12Γ1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with PNP Normally Open configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 500Hz ensures quick and accurate performance. Now's the Time to Secure a Quote for your requirement of Cylindrical Inductive Proximity Sensors. We're committed to offering more favorable pricing and more responsive support than other Traders.
