Autonics PRW08-1.5DP Proximity Sensor
The Autonics PRW08-1.5DP Proximity Sensor features a 1.5mm sensing distance, PNP Normally Open output, and DC 3-wire 12β24VDC operation ensuring stable detection in compact automation setups. Manufactured by Autonics under the Autonics Proximity Sensors range, this model belongs to the Autonics PR Series. It includes a M08 sensing side diameter, Max. 15% hysteresis, and 8Γ8Γ1mm iron standard sensing target. With IP67 protection (IEC standard) and a 1.5kHz response frequency, it ensures high durability and rapid response for precise detection tasks.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRW08-1.5DP |
Autonics PRW08-1.5DP Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M08 |
| Sensing distance | 1.5mm |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Standard sensing target | 8Γ8Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard connector |
| Body length | Standard type |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 1.5kHz |
| Weight | Approx. 44g(approx. 32g) |
Please speak to our Technical Engineer for Cylindrical Inductive Proximity Sensors PRW08-1.5DP at attractive prices. Technical Specs Summary of PRW08-1.5DP includes the key specifications include a sensing distance of 1.5mm designed for a standard target of 8Γ8Γ1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with PNP Normally Open configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 1.5kHz ensures quick and accurate performance. Match Your Needs with a Quote for your requirement of Cylindrical Inductive Proximity Sensors. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
