Autonics PRT30-10DO Proximity Sensor
The Autonics PRT30-10DO Proximity Sensor provides 10mm sensing distance, M30 sensing side diameter, and a Normally Open output using DC 2-wire 12β24VDC for reliable industrial automation detection performance. Manufactured by Autonics, this model is part of the Autonics Proximity Sensors family under the PR Series. It ensures maximum 10% hysteresis, supports a 30Γ30Γ1mm iron target, provides IP67 protection, and operates at a 400Hz response frequency for high-speed, stable sensing in automation systems.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRT30-10DO |
Autonics PRT30-10DO Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 10mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 30Γ30Γ1mm(iron) |
| Current specification | Leakage current: Max. 0.6mA |
| Control output | Normally Open |
| Wire type and power | DC 2-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 3.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 400Hz |
| Weight | Approx. 207g(approx. 170g) |
The Autonics PRT30-10DO is a precision-built Proximity Sensor engineered to ensure stable and accurate metal detection in demanding industrial environments. It operates on a DC 2-wire 12β24VDC supply and features a Normally Open output configuration, providing easy integration with various automation control systems. With a 10mm sensing distance and M30 flush-type design, this Autonics PRT30-10DO Proximity Sensor delivers reliable non-contact detection suitable for high-speed processes. It achieves consistent performance through a 400Hz response frequency and maintains a maximum leakage current of just 0.6mA. Built with a nickel-plated brass housing, the sensor provides excellent mechanical strength and protection against vibration, while its IP67 protection structure ensures resistance to dust, oil, and moisture. Capable of operating between -25Β°C and 70Β°C and withstanding up to 95% relative humidity, the PRT30-10DO guarantees dependable results even in harsh industrial environments. Its simple 2-wire connection design minimizes wiring time, making it a preferred choice among OEMs and control panel builders seeking efficiency, accuracy, and reliability in production systems.
The Autonics PRT30-10DO Proximity Sensor is widely applied in conveyors, assembly lines, machine tools, and packaging systems where quick and accurate detection of metal components is essential. Its rugged construction and Cylindrical Inductive Proximity Sensor design make it suitable for repetitive operations in factories, ensuring minimal downtime and consistent results. Maintenance engineers use this Autonics PRT30-10DO model for detecting presence, position, or movement of parts in CNC machines, presses, and robotic systems. With its reliable Normally Open control output and wide voltage compatibility, it enhances automation safety and productivity. The high environmental tolerance and robust sealing extend service life, making it ideal for heavy-duty industrial use. Whether for retrofitting or new installations, the PRT30-10DO Autonics remains a trusted solution for manufacturers requiring accuracy, performance, and long-term reliability in non-contact sensing applications.
The Autonics PRT30-10DO Proximity Sensor is part of Autonicsβ advanced range of Cylindrical Inductive Proximity Sensors known for their robust performance and easy installation. With a focus on precision and durability, this Autonics PRT30-10DO model ensures error-free metal detection in fast-moving automation setups. Its flush-mountable M30 body and IP67-rated enclosure provide long-lasting protection, while the efficient DC 2-wire circuit minimizes power loss. Industrial buyers and automation specialists prefer this sensor for its accuracy, fast response, and energy-efficient operation. As a reliable Autonics PRT30-10DO Proximity Sensor, it supports high-performance industrial systems where precision, consistency, and environmental durability are critical to smooth operation.
