Autonics PRL30-15DN Proximity Sensor
The Autonics PRL30-15DN Proximity Sensor provides 15mm sensing distance, M30 sensing side diameter, and a reliable NPN Normally Open output with DC 3-wire 12β24VDC power for efficient industrial automation detection. Manufactured by Autonics under the Autonics Proximity Sensors range, this model is part of the PR Series. It ensures maximum 10% hysteresis, supports a 45Γ45Γ1mm iron target, provides IP67 protection, and operates at a 200Hz response frequency for accurate, high-speed sensing in industrial environments.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRL30-15DN |
Autonics PRL30-15DN Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 15mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 45Γ45Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-flush |
| Cable Standard/material | Standard cable |
| Body length | Long body |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 200Hz |
| Weight | Approx. 247g(approx. 210g) |
The Autonics PRL30-15DN is designed with an M30 sensing head and provides a 15mm sensing distance for stable detection of iron targets sized 45Γ45Γ1mm. Its non-flush mounting style creates a wider electromagnetic field, ensuring consistent operation in conveyor systems and automation setups where detection depth is critical.
This Cylindrical Inductive Proximity Sensor operates on a DC 3-wire 12β24VDC power supply and delivers an NPN Normally Open output for seamless integration with PLCs and control panels. With a maximum current consumption of 10mA, residual voltage of just 1.5V, and a 200Hz response frequency, it ensures reliable switching, energy efficiency, and dependable results in medium-speed automation environments.
Built to endure demanding shop-floor conditions, the PRL30-15DN comes with a nickel-plated brass body, PBT sensing face, and an IP67 protection rating, making it resistant to dust, oil, and water splashes. It operates across -25Β°C to 70Β°C with up to 95% humidity, ensuring reliability in fabrication plants, packaging lines, and press shops. Its long-body structure supports deep mounting, while PVC or oil-resistant PVC cable options make it versatile for diverse machinery. Trusted for durability, accuracy, and Autonics engineering, this model has become a preferred sensor for OEMs, maintenance teams, and automation professionals across India. For more details, visit the official Autonics Proximity Sensors page.
Fabrication units and packaging stations benefit from its 15mm long sensing range, which minimizes the need for precise part placement and increases throughput. Its 200Hz response frequency makes it suitable for medium-speed applications, such as indexing machines, automated feeders, and rotating equipment monitoring. With a rugged IP67 build, it continues to perform even in environments exposed to oil, dust, or coolant.
For maintenance engineers, the sensorβs 3-wire DC system simplifies integration with PLCs and control panels, reducing diagnostic and replacement time. Senior professionals value its long-term reliability in shop-floor conditions, while engineering students and trainers use it in automation labs to demonstrate the working principles of Cylindrical Inductive Proximity Sensors. By combining dependable sensing, ease of use, and Autonics engineering quality, the PRL30-15DN proves its importance in both teaching and real-world industry applications.
