Autonics PRDWT18-7DC-IV Proximity Sensor
The Autonics PRDWT18-7DC-IV Proximity Sensor offers 7mm sensing distance, Normally Closed output, Shield(flush), M18, Standard type, 250Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PRD Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRDWT18-7DC-IV |
Autonics PRDWT18-7DC-IV Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M18 |
| Sensing distance | 7mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 20Γ20Γ1mm(iron) |
| Current specification | Leakage current: Max. 0.6mA |
| Control output | Normally Closed |
| Wire type and power | DC 2-wire type 12-24VDC @(=) |
| Installation | Shield(flush) |
| Cable Standard/material | Oil resistant cable(IEC standard) |
| Body length | Standard type |
| Residual voltage | Max. 3.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Brass(nickel plated) |
| Response frequency | 250Hz |
| Weight | β 62g (β 80g) |
Talk to Our Engineer for Long-Distance Inductive Sensor PRDWT18-7DC-IV with exclusive offers. Core System Specifications of PRDWT18-7DC-IV are the key specifications include a sensing distance of 7mm designed for a standard target of 20Γ20Γ1mm(iron). This sensor features a Current specification of Leakage current: Max. 0.6mA and a control output with Normally Closed configurations. It operates on a Wire type and power DC 2-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 250Hz ensures quick and accurate performance. Don't Miss Out on a Quote for your requirement of Long-Distance Inductive Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
