Autonics PRDWT08-2DO-V Proximity Sensor
The Autonics PRDWT08-2DO-V Proximity Sensor offers 2mm sensing distance, Normally Open output, Shield(flush), M8, Standard type, 1kHz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PRD Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRDWT08-2DO-V |
Autonics PRDWT08-2DO-V Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M8 |
| Sensing distance | 2mm |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Standard sensing target | 8Γ8Γ1mm(iron) |
| Current specification | Leakage current: Max. 0.8mA |
| Control output | Normally Open |
| Wire type and power | DC 2-wire type 12-24VDC @(=) |
| Installation | Shield(flush) |
| Cable Standard/material | Oil resistant cable |
| Body length | Standard type |
| Residual voltage | Max. 3.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Case/Nut: Nikel plated Brass (case of PRDβ‘T08: SUS303), Washer: Nikel plated Iron, Sensing surface: Heat-resistant ABS (PRDβ‘T08: PBT)Standard cable(Black): Polyvinyl chloride(PVC), Oil resistant cable(Gray): Oil resistant Polyvinyl chloride(PVC) |
| Response frequency | 1kHz |
| Weight | Approx. 25g(approx. 45g) |
Please speak to our Technical Engineer for Long-Distance Inductive Sensor PRDWT08-2DO-V at attractive prices. Technical Specs Summary of PRDWT08-2DO-V includes the key specifications include a sensing distance of 2mm designed for a standard target of 8Γ8Γ1mm(iron). This sensor features a Current specification of Leakage current: Max. 0.8mA and a control output with Normally Open configurations. It operates on a Wire type and power DC 2-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 1kHz ensures quick and accurate performance. Match Your Needs with a Quote for your requirement of Long-Distance Inductive Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
