Autonics PRDCM12-8DN Proximity Sensor
The Autonics PRDCM12-8DN Proximity Sensor offers a 8mm sensing distance with NPN Normally Open output and a durable M12 sensing side diameter ideal for precise detection in automation systems. Manufactured by Autonics, this dependable Autonics Proximity Sensor is available under the Autonics PRD Series, known for reliable operation in industrial environments. It operates on DC 3-wire type 12β24VDC power, features a robust IP67 protection structure, and supports a 400Hz response frequency. This model detects 25Γ25Γ1mm (iron) standard targets with maximum 10% hysteresis, ensuring stable and consistent performance in demanding automation applications.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRDCM12-8DN |
Autonics PRDCM12-8DN Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 8mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 25Γ25Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-shield(non-flush) |
| Cable Standard/material | Standard connector |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Brass(nickel plated) |
| Response frequency | 400Hz |
| Weight | β 20g (β 49g) |
Call us for Long-Distance Inductive Sensor PRDCM12-8DN at the best rates. Technical Attributes of PRDCM12-8DN are the key specifications include a sensing distance of 8mm designed for a standard target of 25Γ25Γ1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with NPN Normally Open configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 400Hz ensures quick and accurate performance. Unlock Exclusive Pricing with a Quote for your requirement of Long-Distance Inductive Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
