Autonics PRDAT18-7DO Proximity Sensor
The Autonics PRDAT18-7DO Proximity Sensor offers 7mm sensing distance, Normally Open output, Shield(flush), M18, Standard type, 250Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PRD Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRDAT18-7DO |
Autonics PRDAT18-7DO Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M18 |
| Sensing distance | 7mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 20Γ20Γ1mm(iron) |
| Current specification | Leakage current: Max. 0.6mA |
| Control output | Normally Open |
| Wire type and power | DC 2-wire type 12-24VDC @(=) |
| Installation | Shield(flush) |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 3.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Brass(teflon coated) |
| Response frequency | 250Hz |
| Weight | β 122g (β 134g) |
Call us for Long-Distance Inductive Sensor PRDAT18-7DO at the best rates. Technical Attributes of PRDAT18-7DO are the key specifications include a sensing distance of 7mm designed for a standard target of 20Γ20Γ1mm(iron). This sensor features a Current specification of Leakage current: Max. 0.6mA and a control output with Normally Open configurations. It operates on a Wire type and power DC 2-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 250Hz ensures quick and accurate performance. Unlock Exclusive Pricing with a Quote for your requirement of Long-Distance Inductive Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
