Autonics PRD12-8D-IL2 Proximity Sensor
The Autonics PRD12-8D-IL2 Proximity Sensor offers 8mm sensing distance, Max. 100mA output, Non-flush, M12, Standard type, 400Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PRD Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRD12-8D-IL2 |
Autonics PRD12-8D-IL2 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 8mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 25Γ25Γ1mm(iron) |
| Current specification | IO-Link mode: β€ 25 mA, SIO mode: β€ 20 mA |
| Control output | Max. 100mA |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Standard cable(Black): Polyvinyl chloride(PVC), Oil resistant cable(Gray): Polyvinyl chloride(Oil resistant PVC), Case/Nut: Nikel plated Brass, Washer: Nikel plated Iron, Sensing surface: PBT |
| Response frequency | 400Hz |
| Weight | β 62g (β 74g) |
Send Your Inquiry for Long-Distance Inductive Sensor PRD12-8D-IL2 with cost-effective solutions. Essential Technical Specs of PRD12-8D-IL2 are the key specifications include a sensing distance of 8mm designed for a standard target of 25Γ25Γ1mm(iron). This sensor features a Current specification of IO-Link mode: β€ 25 mA, SIO mode: β€ 20 mA and a control output with Max. 100mA configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -25 to 70β and can be stored at temperatures ranging. A response frequency of 400Hz ensures quick and accurate performance. Capture the Best Deal with a Quote for your requirement of Long-Distance Inductive Sensor. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
