Autonics PRD08-4DN-V Proximity Sensor
The Autonics PRD08-4DN-V Proximity Sensor offers 4mm sensing distance, NPN Normally Open output, Non-flush, M8, Standard type, 800Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PRD Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRD08-4DN-V |
Autonics PRD08-4DN-V Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M8 |
| Sensing distance | 4mm |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Standard sensing target | 12Γ12Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-flush |
| Cable Standard/material | Oil resistant cable |
| Body length | Standard type |
| Affection by temperature | β€ Β± 10 % for sensing distance at ambient temperature 20 β(DIA. of sensing side Γ 8 mm: β€ Β± 15 %) |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 800Hz |
| Weight | Approx. 43g(approx. 63g) |
Autonics engineered the PRD08-4DN-V Long-Distance Inductive Sensor with an M8 housing and a 4mm sensing distance, ideal for detecting 12Γ12Γ1mm iron targets. It runs on a DC 3-wire 12β24VDC supply and provides an NPN Normally Open output for seamless PLC integration. With an 800Hz response frequency, it ensures high-speed detection while keeping current consumption below 10mA and residual voltage under 2V. The IP67-rated brass body and oil-resistant cable deliver reliable performance in harsh environments with dust, oil, or moisture. Operating between β25β and 70β, the PRD08-4DN-V combines compact size, efficiency, and long service life for demanding automation tasks.
Engineers use the Autonics PRD08-4DN-V Proximity Sensor in conveyors, packaging machines, and robotic systems where compact and accurate sensing is essential. Maintenance teams appreciate its durability in oily or dusty factory conditions, while system integrators value the non-flush design for flexible mounting. Students and professionals also benefit from its role in demonstrating high-frequency proximity detection. By offering consistent contactless feedback, the PRD08-4DN-V helps improve safety, minimize downtime, and boost productivity in modern automation setups.
The Autonics Proximity Sensors series reflects proven quality and innovation in industrial automation. The PRD08-4DN-V delivers stable performance, compact design, and precise results, making it suitable for OEMs, distributors, and plant operators. Whether engineers search for PRD08-4DN-V, PRD08, or need details about the range of proximity sensor models, this unit is recognized as a reliable choice. With trusted build quality and consistent output, it reinforces Autonicsβ position as a leader in advanced sensing solutions.
