Autonics PRCM18-5DN Proximity Sensor
The Autonics PRCM18-5DN Proximity Sensor features a 5mm sensing distance with NPN Normally Open output and a durable M18 sensing side diameter for precise metal detection. Manufactured by Autonics, this proximity sensor from the PR Series ensures stable performance with hysteresis max. 10 of sensing distance and a standard sensing target 18Γ18Γ1mm (iron). It operates on a DC 3-wire type 12β24VDC power supply, provides a 500Hz response frequency, and offers IP67 protection for reliable use in industrial environments.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRCM18-5DN |
Autonics PRCM18-5DN Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M18 |
| Sensing distance | 5mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 18Γ18Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard connector |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 500Hz |
| Weight | Approx. 61g(approx. 49g) |
The Autonics PRCM18-5DN is engineered with an M18 flush-mount body and delivers a reliable 5mm sensing distance, optimized for detecting 18Γ18Γ1mm iron targets. Operating on DC 3-wire 12β24VDC, it integrates easily with PLC control systems using an NPN Normally Open output. With low current consumption of just 10mA, residual voltage under 1.5V, and a response frequency of 500Hz, this model provides efficient, stable, and high-speed performance. Its nickel-plated brass housing with a PBT sensing face ensures rugged protection, while the IP67 rating offers resistance to dust, oil, and water. Lightweight at 61g, it installs effortlessly in compact machine panels or tight automation spaces without compromising reliability.
Industrial engineers trust the Autonics PRCM18-5DN for demanding applications such as conveyor part detection, indexing in rotary tables, and end-position verification in pneumatic actuators. Its rugged build ensures durability in vibration-heavy setups, while its wide operating temperature range of -25Β°C to +70Β°C allows consistent performance across diverse shopfloor conditions. Maintenance teams prefer its easy wiring and long operating life, while engineering students use it to study inductive sensing technology in real-world automation projects. With energy-efficient operation and strong build quality, the PRCM18-5DN stands out among Cylindrical Inductive Proximity Sensors for precision and endurance.
Procurement professionals frequently shortlist PRCM18-5DN when evaluating reliable sensor solutions, ensuring cost efficiency and compatibility with existing automation systems. Searches for βPRCM18-5DN,β βPRCM18,β and β5DNβ highlight its strong demand across industries. With proven accuracy, rugged construction, and brand reliability, the Autonics PRCM18-5DN Proximity Sensor continues to be a trusted choice for long-term industrial applications. For official specifications, visit the Autonics Proximity Sensors catalog.
