Procurement teams shortlist PRCM12-2AC with Autonics Photoelectric Sensor, Contrinex Proximity Sensor and Autonics Tcn4 Series, aligning budget approvals, warranty terms, and multisite availability for smoother rollout across plants.
Autonics PRCM12-2AC Proximity Sensor
The Autonics PRCM12-2AC Proximity Sensor offers 2mm sensing distance, Normally Closed output, Flush, M12, Standard type, 20Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PR Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRCM12-2AC |
Autonics PRCM12-2AC Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 2mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 12Γ12Γ1mm(iron) |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Closed |
| Wire type and power | AC 2-wire type 100-240VAC~ |
| Installation | Flush |
| Cable Standard/material | Standard connector |
| Body length | Standard type |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Residual voltage | Max. 10V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Brass(nickel plated) |
| Response frequency | 20Hz |
| Weight | Approx. 42g(approx. 30g) |
Call us for Cylindrical Inductive Proximity Sensors PRCM12-2AC at the best rates. Technical Attributes of PRCM12-2AC are the key specifications include a sensing distance of 2mm designed for a standard target of 12Γ12Γ1mm(iron). This sensor features a Current specification of Leakage current: Max. 2.5mA and a control output with Normally Closed configurations. It operates on a Wire type and power AC 2-wire type 100-240VAC~. Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70β, storage: -30 to 80β and can be stored at temperatures ranging. A response frequency of 20Hz ensures quick and accurate performance. Unlock Exclusive Pricing with a Quote for your requirement of Cylindrical Inductive Proximity Sensors. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
