Autonics PR30-15AC Proximity Sensor
The Autonics PR30-15AC Proximity Sensor features a 15mm sensing distance with Normally Closed output and a durable M30 sensing side diameter for accurate metal detection. Manufactured by Autonics, this proximity sensor from the PR Series ensures stable operation with hysteresis max. 10 of sensing distance and a standard sensing target 45Γ45Γ1mm (iron). It operates on an AC 2-wire type 100β240VAC~ power supply, supports a 20Hz response frequency, and provides robust IP67 protection suitable for demanding industrial environments.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR30-15AC |
Autonics PR30-15AC Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 15mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 45Γ45Γ1mm(iron) |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Closed |
| Wire type and power | AC 2-wire type100-240VAC~ |
| Installation | Non-flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Residual voltage | Max. 10V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Brass(nickel plated) |
| Response frequency | 20Hz |
| Weight | Approx. 207g(approx. 170g) |
The Autonics introduces the PR30-15AC, a high-performance Cylindrical Inductive Proximity Sensor engineered for precise metal detection in rugged industrial environments. This model features a M30 sensing side and offers a reliable sensing distance of 15mm, specifically optimized for detecting standard targets like 45Γ45Γ1mm iron plates. Designed with a non-flush mounting style, it enables deeper sensing depth, making it ideal for applications involving larger or unevenly positioned components.
The PR30-15AC supports a wide AC 2-wire voltage range of 100β240VAC~, and delivers a Normally Closed control output, ensuring compatibility with legacy and high-voltage PLC systems. Safety is enhanced through its double insulation structure with 1kV dielectric strength, protecting both operator and equipment. With a low leakage current of 2.5mA and residual voltage under 10V, signal integrity remains stable in noisy conditions. Its robust nickel-plated brass housing and IP67 rating offer excellent resistance to water, oil, and dust. A response frequency of 20Hz allows for efficient operation in moderate-speed automation setups, while the wide operating range of -25Β°C to 70Β°C ensures uninterrupted functionality.
The PR30-15AC is part of the trusted Autonics Proximity Sensors range known for durability and ease of integration. To compare other proximity sensors, refer to our Autonics Proximity Sensors category. For sensor controllers and complete automation solutions, see our Autonics brand page.
Industrial teams in packaging, textiles, and bottling rely on the PR30-15AC for low-maintenance, long-term use. Engineering colleges also use this model to train students in practical AC sensing technology and installation standards followed in real-world factories.
