Autonics PR18-5DP-V Proximity Sensor
The Autonics PR18-5DP-V Proximity Sensor offers 5mm sensing distance, PNP Normally Open output, Flush, M18, Standard type, 500Hz Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PR Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR18-5DP-V |
Autonics PR18-5DP-V Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M18 |
| Sensing distance | 5mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 18Γ18Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Oil resistant cable |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 500Hz |
| Weight | Approx. 122g(approx. 110g) |
Autonics has developed the PR18-5DP-V Cylindrical Inductive Proximity Sensor with an M18 flush design and 5mm sensing distance, optimized for 18Γ18Γ1mm iron targets. Operating on a DC 3-wire system with 12β24VDC input, it provides a PNP Normally Open output that integrates easily with PLCs and controllers. With a 500Hz response frequency, current consumption below 10mA, and residual voltage under 1.5V, the sensor ensures energy-efficient, high-speed detection. Its nickel-plated brass body, oil-resistant cable, and IP67 protection enable stable operation in harsh conditions including dust, water, and oil. Reliable across β25β to 70β and up to 95% humidity, the PR18-5DP-V is trusted for continuous performance in demanding industrial setups.
Engineers use the Autonics PR18-5DP-V Proximity Sensor in conveyor lines, robotic stations, packaging equipment, and machining tools where accuracy is essential. Maintenance teams appreciate its rugged build that minimizes downtime, while integrators benefit from the straightforward installation in standard M18 slots. For students and training centers, this sensor offers a practical way to understand non-contact detection technology. By providing reliable feedback even under vibration, oil, or moisture, the PR18-5DP-V helps industries improve both safety and productivity.
The Autonics Proximity Sensors range is well known for durability and performance in industrial automation. The PR18-5DP-V combines compact design, robust construction, and precise feedback, making it a dependable choice for OEMs and plant operators. Whether searched as PR18-5DP-V, Autonics PR18-5DP-V, or simply 5DP, this model stands out as a proven solution for automation engineers and buyers who require stable, long-term sensing results.
