Autonics PR08-2DP2 Cylindrical Inductive Proximity Sensor
PR08-2DP2 cylindrical inductive proximity sensor provides M08 diameter, 2mm sensing distance, non-flush mounting, and PNP normally closed output operation. Manufactured by Autonics, this Autonics Cylindrical Inductive Proximity Sensors model is part of Autonics Proximity Sensors and the PR Series, operating on DC 3-wire 12–24V supply with IP67 protection, 1kHz response frequency, and controlled current consumption.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR08-2DP2 |
Autonics PR08-2DP2 Cylindrical Inductive Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M08 |
| Sensing distance | 2mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 8×8×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Closed |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Non-flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 1kHz |
| Weight | Approx. 64g(approx. 52g) |
The Autonics PR08-2DP2 Cylindrical Inductive Proximity Sensors is designed for industrial automation systems requiring consistent inductive detection. This model supports a M08 cylindrical body, 2mm sensing distance, and PNP normally closed output with DC 3-wire 12–24V operation. It belongs to the PR Series from Autonics and is commonly specified in Indian industrial automation installations.
In industrial environments, the PR08-2DP2 proximity sensor is applied in conveyors, packaging machinery, automated assembly lines, and material handling systems. Non-flush installation allows reliable sensing performance, while stable inductive detection supports accurate object presence monitoring. This helps maintain dependable switching behavior during continuous production and automated control operations.
The PR08-2DP2 from Autonics delivers dependable sensing supported by IP67 protection and defined electrical characteristics. As part of the Autonics PR Series, it aligns with standardized sensing targets and installation practices. This Autonics Cylindrical Inductive Proximity Sensors model remains suitable for engineers seeking reliable proximity detection in demanding industrial automation environments.
