Autonics PR08-1.5DP2 Cylindrical Inductive Proximity Sensor
PR08-1.5DP2 cylindrical inductive proximity sensor features M08 diameter, 1.5mm sensing distance, flush mounting, and PNP normally closed output operation. Manufactured by Autonics, this Autonics Cylindrical Inductive Proximity Sensors model belongs to Autonics Proximity Sensors and the PR Series, supporting DC 3-wire 12–24V supply, IP67 protection, 1.5kHz response frequency, and controlled current consumption.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR08-1.5DP2 |
Autonics PR08-1.5DP2 Cylindrical Inductive Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M08 |
| Sensing distance | 1.5mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 8×8×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Closed |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 1.5kHz |
| Weight | Approx. 64g(approx. 52g) |
The Autonics PR08-1.5DP2 Cylindrical Inductive Proximity Sensors is specified for industrial automation environments requiring compact inductive sensing. This model provides a M08 cylindrical form, 1.5mm sensing distance, and PNP normally closed output with DC 3-wire 12–24V operation. It belongs to the PR Series from Autonics and is applied across Indian automation systems where defined switching behavior is required.
In industrial applications, the PR08-1.5DP2 proximity sensor is used in conveyors, packaging machinery, automated assembly stations, and material handling equipment. Flush installation enables integration into tight machine layouts, while stable inductive detection supports consistent object sensing. This helps maintain accurate positioning and reliable signal output across repetitive production cycles.
The PR08-1.5DP2 from Autonics maintains dependable sensing performance with IP67 protection and standardized electrical characteristics. As part of the Autonics PR Series, it aligns with industrial installation practices and sensing targets. This Autonics Cylindrical Inductive Proximity Sensors model remains suitable for engineers and plant operators seeking reliable proximity detection in long-term industrial automation use.
