Autonics PR08-1.5DP Cylindrical Inductive Proximity Sensor
Autonics PR08-1.5DP is a cylindrical inductive proximity sensor with 1.5mm sensing distance, M08 diameter, and PNP normally open output. Manufactured by Autonics, this Autonics Cylindrical Inductive Proximity Sensors model belongs to the PR Series and features DC 3-wire 12–24VDC supply, max 10mA current consumption, flush installation, 1.5kHz response frequency, IP67 protection structure, standard cable type, and approx. 64g weight for industrial automation applications in India.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR08-1.5DP |
Autonics PR08-1.5DP Cylindrical Inductive Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M08 |
| Sensing distance | 1.5mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 8×8×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 2V |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 1.5kHz |
| Weight | Approx. 64g(approx. 52g) |
PR08-1.5DP is part of Autonics Cylindrical Inductive Proximity Sensors designed for industrial automation sensing tasks. The Autonics PR08-1.5DP provides a 1.5mm sensing distance in a compact M08 diameter housing with PNP normally open output and IP67 protection. This model belongs to the PR Series and operates on DC 3-wire 12–24VDC supply with low current consumption. PR08 is engineered for stable metal detection where space is limited and consistent response frequency of 1.5kHz is required.
In industrial automation environments, PR08-1.5DP is used in conveyors, packaging lines, assembly stations, and small automation fixtures. The cylindrical threaded body allows flush mounting in panels and machinery. Autonics PR08-1.5DP ensures reliable metal target detection such as 8×8×1mm iron pieces, maintaining stable output signals for PLC input systems. Its IP67 structure supports operation in dust-prone and light moisture conditions commonly found in manufacturing plants.
PR08-1.5DP from Autonics PR Series maintains precise switching performance with defined hysteresis up to 10% of sensing distance. As part of Autonics Cylindrical Inductive Proximity Sensors, it is suitable for machine builders and maintenance engineers requiring compact M8 inductive sensing. With PNP normally open configuration and standard cable wiring, PR08 integrates easily into 12–24VDC industrial control panels across Indian automation sectors.
