Autonics PL4G-201-RG Tower Light
The Autonics PL4G-201-RG Tower Light offers Steadyfunction, 12VAC/DC power supply, Red, Green lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Tower Light category, this model belongs to the Autonics PL4 Series.
| Brand | Autonics |
| Product Type | Tower Lights |
| Model Number | PL4G-201-RG |
Autonics PL4G-201-RG Tower Light β Technical Specifications
| Specification | Value |
|---|---|
| Function | Steady |
| Power supply | 12VAC/DC |
| Current consumption | 0.10A |
| LED color | Red, Green |
| Lens color | Red, Green |
| Dimension | D45mm |
| Mounting direction | Upward only |
| Connection type | Lead wire connection |
| Cable specification | UL1007/22AWG |
| Ambient temperature | -20~40β |
| Storage ambient temperature | -20~70β |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100M⦠or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP63 |
