Autonics MX4W-V-FN Digital Panel Meter
The Autonics MX4W-V-FN Digital Panel Meter offers 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method display method, 19mm character height, -9999 to 9999(4digit) display range, DC voltageAC voltage, Frequency measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MX4W Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MX4W-V-FN |
Autonics MX4W-V-FN Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method |
| Character height | 19mm |
| Max. display Range | -9999 to 9999(4digit) |
| Measurement | DC voltageAC voltage, Frequency |
| Input specification | DC ±500mV, ±200mV, ±50mV, ±20V, ±5V, 1-5V, ±2V, ±500V, ±200V, ±50V, AC 0-500mV, 0-200mV, 0-50mV, 0-20V, 0-5V, 0-2V, 0-500V, 0-200V, 0-110V, 0-50V |
| AC Measurement | Select RMS value /AVG value measurement methods |
| Power supply | 24-240VAC~ 50/60Hz, 24-240VDC @(=) |
| Output_Main Output(Comparative Value) | Indicator |
| Display accuracy | 23±5℃ - DC input: ±0.1% F .S. ±2digit, AC input: ±0.3% F .S. ±3digit ※The teminal for 5A of current input, ±0.3% F .S. ±3digit, 0~50℃ - AC/DC input: ±0.5% F .S. ±3digit ※The teminal for 5A of current input, ±1% F .S. ±3digit |
| Power Factor Display | Power factor display are available when input type is DC. |
| Max. allowable input | • DC input: approx. -110 to 110% of each measurement input range(when not using minus input: -10 to 110%)• AC input: approx. 110% of each measurement input range |
| Display cycle | 0.2 to 5.0 sec (select per 0.1 sec) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 100g(approx. 77g) |
The Autonics MX4W-V-FN combines precision with flexibility, offering a 12-segment LCD display and a large 19mm character height for excellent readability. Supporting a wide measurement range from -9999 to 9999, it handles both DC and AC voltage inputs such as ±500V, ±200V, 0–5V, and 1–5V, along with frequency monitoring. Engineers can select between RMS or AVG measurement modes to suit variable load conditions. With 24–240V AC/DC power supply compatibility, this LCD Display Multi Panel Meter integrates smoothly into diverse electrical systems. Accuracy is maintained at ±0.1% F.S. for DC and ±0.3% F.S. for AC, with a configurable refresh cycle of 0.2 to 5 seconds ensuring timely updates. Built for durability, it comes with IP54 front protection against dust and moisture, while weighing only about 100g, making installation simple in compact control panels.
The Autonics MX4W-V-FN Digital Panel Meter is widely adopted in manufacturing plants, energy systems, HVAC, motor control panels, and automation labs where precision monitoring is vital. Its reliability helps maintenance engineers detect voltage fluctuations, frequency shifts, and abnormal load conditions quickly. For students and junior engineers, the simple interface and clear LCD display provide a valuable learning experience in signal measurement. Senior automation engineers appreciate its accuracy, flexible input options, and communication readiness, which support integration with PLCs and SCADA systems. Whether upgrading legacy panels or building new automation systems, the MX4W-V-FN delivers dependable, real-time monitoring trusted across industries. Learn more on the official Autonics Panel Meters page or the full Autonics Sensors & Controllers catalog.
