Autonics MX4W-A-FN LCD Type Digital Panel Meter
MX4W-A-FN is an Autonics LCD Type Digital Panel Meter with 4-digit LCD display measuring DC current AC current frequency. Manufactured by Autonics, this meter is part of Autonics Digital Panel Meter range under the MX4W Series, featuring -9999 to 9999 display range, 19mm character height, LCD display method, indicator output, and approximate 100g weight.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MX4W-A-FN |
Autonics MX4W-A-FN LCD Type Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method |
| Character height | 19mm |
| Max. display Range | -9999 to 9999(4digit) |
| Measurement | DC currentAC current, Frequency |
| Input specification | DC ΓΒ±20mA, 4-20mA, ΓΒ±5mA, ΓΒ±2mA, ΓΒ±500mA, ΓΒ±200mA, ΓΒ±50mA, ΓΒ±5A, ΓΒ±2A,AC 0-20mA, 0-5mA, 0-2mA, 0-500mA, 0-200mA, 0-50mA, 0-5A, 0-2A |
| AC Measurement | Select RMS value /AVG value measurement methods |
| Power supply | 24-240VAC~ 50/60Hz, 24-240VDC @(=) |
| Output_Main Output(Comparative Value) | Indicator |
| Display accuracy | 23ΓΒ±5Γ’βΖ - DC input: ΓΒ±0.1% F .S. ΓΒ±2digit, AC input: ΓΒ±0.3% F .S. ΓΒ±3digit Γ’β¬Β»The teminal for 5A of current input, ΓΒ±0.3% F .S. ΓΒ±3digit, 0~50Γ’βΖ - AC/DC input: ΓΒ±0.5% F .S. ΓΒ±3digit Γ’β¬Β»The teminal for 5A of current input, ΓΒ±1% F .S. ΓΒ±3digit |
| Power Factor Display | Power factor display are available when input type is DC. |
| Max. allowable input | Γ’β¬Β’ DC input: approx. -110 to 110% of each measurement input range(when not using minus input: -10 to 110%)Γ’β¬Β’ AC input: approx. 110% of each measurement input range |
| Display cycle | 0.2 to 5.0 sec (select per 0.1 sec) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 100g(approx. 77g) |
The MX4W-A-FN Autonics LCD Type Digital Panel Meter is designed for multi-parameter electrical monitoring in industrial automation systems. This MX4W-A-FN Autonics LCD Type Digital Panel Meter provides DC current, AC current, and frequency measurement using a 4-digit LCD display with a -9999 to 9999 display range and 19mm character height. It belongs to the MX4W Series and is used where clear numerical indication is required.
In industrial environments, the MX4W-A-FN Autonics LCD Type Digital Panel Meter is commonly installed on control panels for conveyors, packaging equipment, assembly lines, and automation systems. It allows operators to monitor current and frequency values accurately, supporting stable electrical operation and routine process supervision without complex configuration.
The MX4W-A-FN Digital Panel Meter offers consistent electrical indication through its LCD display structure and defined measurement functions. As part of the MX4W Series, it reflects Autonics manufacturing reliability and suitability for industrial automation panels. This Autonics LCD Type Digital Panel Meter remains appropriate for applications requiring dependable visual monitoring of electrical parameters.
