Autonics MX4W-A-F2 Digital Panel Meter
The Autonics MX4W-A-F2 Digital Panel Meter offers 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method display method, 19mm character height, -9999 to 9999(4digit) display range, DC currentAC current, Frequency measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MX4W Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MX4W-A-F2 |
Autonics MX4W-A-F2 Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method |
| Character height | 19mm |
| Max. display Range | -9999 to 9999(4digit) |
| Measurement | DC currentAC current, Frequency |
| Input specification | DC ±20mA, 4-20mA, ±5mA, ±2mA, ±500mA, ±200mA, ±50mA, ±5A, ±2A,AC 0-20mA, 0-5mA, 0-2mA, 0-500mA, 0-200mA, 0-50mA, 0-5A, 0-2A |
| AC Measurement | Select RMS value /AVG value measurement methods |
| Power supply | 24-240VAC~ 50/60Hz, 24-240VDC @(=) |
| Output_Main Output(Comparative Value) | PNP open collector output |
| Display accuracy | 23±5℃ - DC input: ±0.1% F .S. ±2digit, AC input: ±0.3% F .S. ±3digit ※The teminal for 5A of current input, ±0.3% F .S. ±3digit, 0~50℃ - AC/DC input: ±0.5% F .S. ±3digit ※The teminal for 5A of current input, ±1% F .S. ±3digit |
| Power Factor Display | Power factor display are available when input type is DC. |
| Max. allowable input | • DC input: approx. -110 to 110% of each measurement input range(when not using minus input: -10 to 110%)• AC input: approx. 110% of each measurement input range |
| Display cycle | 0.2 to 5.0 sec (select per 0.1 sec) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 100g(approx. 77g) |
Get A Quote for Autonics LCD Display Multi Panel Meter MX4W-A-F2 at the best price. Here are the brief Technical Specifications of MX4W-A-F2 are an 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method with 19mm character height, these displays support a maximum range of -9999 to 9999(4digit). Designed for DC currentAC current, Frequency measurement, they handle DC ±20mA, 4-20mA, ±5mA, ±2mA, ±500mA, ±200mA, ±50mA, ±5A, ±2A,AC 0-20mA, 0-5mA, 0-2mA, 0-500mA, 0-200mA, 0-50mA, 0-5A, 0-2A inputs. The system supports AVG and RMS measurement methods and operates on 24-240VAC~ 50/60Hz, 24-240VDC @(=) power. Outputs include PNP open collector output and . The display accuracy is 23±5℃ - DC input: ±0.1% F .S. ±2digit, AC input: ±0.3% F .S. ±3digit ※The teminal for 5A of current input, ±0.3% F .S. ±3digit, 0~50℃ - AC/DC input: ±0.5% F .S. ±3digit ※The teminal for 5A of current input, ±1% F .S. ±3digit. The ensures precise sampling. Equipped with a , it is ideal for industrial automation applications. Get a quote today for Autonics Display Units with superior accuracy and performance. It's Time to get a Quote for your requirement of LCD Display Multi Panel Meter. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
