Autonics MX4W-A-F1 LCD Display Multi Panel Meter
The MX4W-A-F1 panel meter displays DC and AC current and frequency on a 12-segment LCD for industrial panels. Manufactured by Autonics, this Autonics LCD Display Multi Panel Meter from the MX4W Series supports a -9999 to 9999 display range, 24–240 VAC/DC power supply, IP54 front protection, and multi-color LCD indication for industrial automation use.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MX4W-A-F1 |
Autonics MX4W-A-F1 LCD Display Multi Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method |
| Character height | 19mm |
| Max. display Range | -9999 to 9999(4digit) |
| Measurement | DC currentAC current, Frequency |
| Input specification | DC ±20mA, 4-20mA, ±5mA, ±2mA, ±500mA, ±200mA, ±50mA, ±5A, ±2A,AC 0-20mA, 0-5mA, 0-2mA, 0-500mA, 0-200mA, 0-50mA, 0-5A, 0-2A |
| AC Measurement | Select RMS value /AVG value measurement methods |
| Power supply | 24-240VAC~ 50/60Hz, 24-240VDC @(=) |
| Output_Main Output(Comparative Value) | NPN open collector output |
| Display accuracy | 23±5℃ - DC input: ±0.1% F .S. ±2digit, AC input: ±0.3% F .S. ±3digit ※The teminal for 5A of current input, ±0.3% F .S. ±3digit, 0~50℃ - AC/DC input: ±0.5% F .S. ±3digit ※The teminal for 5A of current input, ±1% F .S. ±3digit |
| Power Factor Display | Power factor display are available when input type is DC. |
| Max. allowable input | • DC input: approx. -110 to 110% of each measurement input range(when not using minus input: -10 to 110%)• AC input: approx. 110% of each measurement input range |
| Display cycle | 0.2 to 5.0 sec (select per 0.1 sec) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 100g(approx. 77g) |
The Autonics MX4W-A-F1 LCD Display Multi Panel Meter is designed for current and frequency monitoring in industrial automation systems. This Autonics panel meter measures DC current, AC current, and frequency using a 12-segment LCD with a -9999 to 9999 four-digit display range. As part of the MX4W Series, the MX4W-A-F1 is commonly installed in electrical control panels across industrial environments.
In applications such as conveyors, packaging equipment, automation lines, and assembly systems, the MX4W-A-F1 supports continuous electrical monitoring. The clear LCD structure allows operators to observe current and frequency conditions easily, while the panel-mounted format supports stable installation. The front IP54 protection ensures reliable operation in environments exposed to dust.
The MX4W-A-F1 Autonics LCD Display Multi Panel Meter reflects Autonics consistency in panel instrumentation. With defined measurement capability, wide power supply compatibility, and structured LCD indication, this MX4W Series model is suitable for long-term industrial automation use in India. Autonics panel meters are widely applied where dependable electrical monitoring and standardized control panel design are required.
