Autonics MT4W-DV-49 DC Voltage Digital Panel Meter
MT4W-DV-49 is an Autonics DC Voltage Digital Panel Meter with 4-digit LED display measuring DC voltage range indicator output. Manufactured by Autonics, this unit belongs to the Autonics Digital Panel Meter category within the MT4W Series, offering -1999 to 9999 display range, 14.2mm character height, DC voltage measurement, and a clear 4-digit 7-segment LED display.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MT4W-DV-49 |
Autonics MT4W-DV-49 DC Voltage Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Character height | 14.2mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | 0-500V, 0-100V, 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | PNP open collector (HI, GO, LO) |
| Output_Sub Output(Display Value) | RS485 communication |
| Display accuracy | Γ’β¬Β’ 23Γ’βΖΓΒ±5Γ’βΖ - ΓΒ± 0.1 % F.S. rdg ΓΒ± 2 digitΓΒ± 0.3 % F.S. rdg ΓΒ± 3 digit max. only for 5A terminal.Γ’β¬Β’ -10Γ’βΖ to 50Γ’βΖ -ΓΒ± 0.5 % F.S. rdg ΓΒ± 3 digit |
| A/D conversion method | ΓΒ£Γβ (Sigma Delta) ADC |
| Sampling cycle | 50ms |
| Hold function | Includes (external hold function) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure | IP56 (front part, IEC standard) |
| Unit weight (packaged weight) | Γ’β°Λ 211 g (Γ’β°Λ 326 g) |
The MT4W-DV-49 Autonics DC Voltage Digital Panel Meter is designed for accurate DC voltage indication in industrial automation systems. This MT4W-DV-49 Autonics DC Voltage Digital Panel Meter features a 4-digit 7-segment LED display with a -1999 to 9999 display range and 14.2mm character height. It belongs to the MT4W Series and is used where stable voltage monitoring is required.
In industrial environments, the MT4W-DV-49 Autonics DC Voltage Digital Panel Meter is commonly installed in control panels for conveyors, packaging machines, automation lines, and assembly systems. It enables operators to monitor DC voltage values clearly, supporting consistent electrical performance and routine supervision across industrial applications.
The MT4W-DV-49 Digital Panel Meter delivers reliable DC voltage indication through a straightforward LED display format. As part of the MT4W Series, it reflects Autonics manufacturing consistency and suitability for industrial automation panels. This Autonics DC Voltage Digital Panel Meter remains appropriate for dependable voltage monitoring in control and electrical panels.
