Autonics MS86S-N20-R Signal Light
The Autonics MS86S-N20-R Signal Light offers Flashingfunction, 220VAC power supply, Red lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Signal Lights category, this model belongs to the Autonics MS Series.
| Brand | Autonics |
| Product Type | Signal Lights |
| Product | MS86S-N20-R |
Autonics MS86S-N20-R Signal Light – Technical Specifications
| Specification | Value |
|---|---|
| Function | Flashing |
| Power supply | 220VAC |
| Current consumption | 0.03A |
| Lens color | Red |
| Dimension | D86mm |
| Mounting direction | Body direct mounting |
| Light source | Xenon lamp 6W |
| Flashing rate | 80±10times/minute |
| Connection type | Lead wire connection |
| Cable specification | UL2464/22AWG×2C |
| Storage ambient temperature | -20~70℃ |
| Ambient temperature | -20~40℃ |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100MΩ or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP65 |
| Weight | Approx. 200g |
