Autonics MS56L-F20-G Signal Light
The Autonics MS56L-F20-G Signal Light offers Steady+Flashingfunction, 220VAC power supply, Green lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Signal Lights category, this model belongs to the Autonics MS Series.
| Brand | Autonics |
| Product Type | Signal Lights |
| Product | MS56L-F20-G |
Autonics MS56L-F20-G Signal Light โ Technical Specifications
| Specification | Value |
|---|---|
| Function | Steady+Flashing |
| Power supply | 220VAC |
| Current consumption | 0.03A |
| LED color | Green |
| Lens color | Green |
| Dimension | D56mm |
| Flashing rate | 80times/minute |
| Connection type | Lead wire connection |
| Cable specification | UL1007/22AWG |
| Storage ambient temperature | -20~70โ |
| Ambient temperature | -15~40โ |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100Mโฆ or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP65 |
| Weight | approx. 82g |
