Autonics MP5Y-24 Digital Panel Meter
The Autonics MP5Y-24 Digital Panel Meter offers 5-digit 7-segment LED display method, 14mm character height, -19999 to 99999 display range, 24VAC~ 50/60Hz, 24-48VDC power supply. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MP5Y Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5Y-24 |
Autonics MP5Y-24 Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| Output_Sub Output(Display Value) | PV transmission (DC0-20mA, DC4-20mA) |
| Measurement range | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : 0.0005Hz to 50kHzΓΒ·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time rangeΓΒ·Operation mode F11, F12, F13, F16 : 0 to 99999ΓΒ·Operation mode F14, F15 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ΓΒ±10% 80mA |
| Input frequency | ΓΒ·Solid state input 1: max. 50kHz (pulse width: min. 10Γ£Ε½Β²)ΓΒ·Solid state input 2: max. 5kHz (pulse width: min. 100Γ£Ε½Β²)Γ’β¬Β»For F7, F8, F9, F10 operation mode, max. 1kHz (pulse width: min. 500Γ£Ε½Β²)ΓΒ·Contact input: max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : F.S.ΓΒ±0.05%rdgΓΒ±1-digitΓΒ·Operation mode F3, F4, F5, F6 : F.S.ΓΒ±0.01%rdgΓΒ±1-digit |
| Prescale function | Direct input method (0.0001Γβ10@(^-9) to 9.9999Γβ10@(^9)) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 230g (approx. 140g) |
The Autonics MP5Y-24, part of the High Performance Digital Pulse Meters series, features a clear 5-digit 7-segment LED display with a 14mm character height and a wide measurement range from -19999 to 99999. Built to handle diverse automation needs, it supports 16 operation modes such as frequency, speed, time, and length measurement. This flexibility makes it ideal for pulse-based systems in high-speed production environments.
With input compatibility for voltage (PNP) and no-voltage (NPN) signals, and an input frequency capability of up to 50kHz, the MP5Y-24 delivers fast, stable readings. The built-in prescale function allows engineers to scale input signals for accurate unit conversion, while its analog output (DC 0β20mA / 4β20mA) enables real-time PV transmission to external systems. Powered by 24VAC or 24β48VDC, and protected with an IP54-rated front panel, this meter ensures reliable operation across ambient temperatures of -10Β°C to 50Β°C. Its performance, precision, and build quality make it a dependable addition to any industrial control setup. View more models at Autonics Panel Meters or the full range at Autonics Sensors & Controllers.
Its analog output simplifies integration with SCADA, HMI, and PLC systems for closed-loop monitoring and process optimization. The intuitive prescale configuration allows engineers to directly convert pulses into meaningful physical units like meters, revolutions, or time durationsβsaving engineering hours and improving panel efficiency.
This Digital Panel Meter is a go-to choice for system integrators, OEMs, and plant engineers who value long-term stability and seamless communication. Its reliable performance across variable signal inputs and challenging industrial environments makes it a trusted tool in India's growing automation sector.
