Autonics MP5W-45 High Performance Digital Pulse Meters
The MP5W-45 is an Autonics High Performance Digital Pulse Meters with 5-digit 7-segment LED display and sixteen operation modes. Manufactured by Autonics, this digital panel meter supports -19999 to 99999 display range, 14mm character height, and 100–240VAC power supply. Positioned under the Autonics Digital Panel Meter category and part of the MP5Y Series, it provides PNP open collector output with IP54 front protection.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5W-45 |
Autonics MP5W-45 High Performance Digital Pulse Meters – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | PNP open collector (HH, H, GO, L, LL) |
| Output_Sub Output(Display Value) | PV transmission (DC0-20mA, DC4-20mA) |
| Measurement range | ·Operation mode F1, F2, F7, F8, F9, F10 : 0.0005Hz to 50kHz·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time range·Operation mode F11, F12, F13, F16 : 0 to 99999·Operation mode F14, F15 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ±10% 80mA |
| Input frequency | ·Solid state input 1: max. 50kHz (pulse width: min. 10㎲)·Solid state input 2: max. 5kHz (pulse width: min. 100㎲)※For F7, F8, F9, F10 operation mode, max. 1kHz (pulse width: min. 500㎲)·Contact input: max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ·Operation mode F1, F2, F7, F8, F9, F10 : F.S.±0.05%rdg±1-digit·Operation mode F3, F4, F5, F6 : F.S.±0.01%rdg±1-digit |
| Prescale function | Direct input method (0.0001×10@(^-9) to 9.9999×10@(^9)) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 334g (approx. 210g) |
The Autonics MP5W-45 High Performance Digital Pulse Meters model is a digital panel meter designed for pulse signal measurement in industrial automation systems. It features a 5-digit 7-segment LED display with a -19999 to 99999 display range for accurate numeric indication. The device supports 16 operation modes covering frequency, speed, cycle, and accumulation measurement. Powered by a 100–240VAC supply, the MP5W-45 belongs to the MP5Y Series used across industrial control panels.
In factory automation environments, the MP5W-45 Autonics High Performance Digital Pulse Meters unit is applied in conveyors, packaging machinery, assembly lines, and monitoring panels. It converts pulse inputs from sensors and encoders into stable visual outputs for operational tracking. The PNP open collector output enables reliable interfacing with control systems, while the IP54-rated front structure supports installation in enclosed industrial panels.
The MP5W-45 Autonics High Performance Digital Pulse Meters solution delivers consistent pulse measurement within structured automation architectures. Its defined output configuration, multi-mode capability, and clear LED indication support continuous industrial operation. Backed by Autonics manufacturing standards, this MP5Y Series digital panel meter remains suitable for environments requiring dependable measurement accuracy and long-term operational stability.
