Autonics MP5W-41 Digital Panel Meter
The Autonics MP5W-41 Digital Panel Meter offers 5-digit 7-segment LED display method, 14mm character height, -19999 to 99999 display range, 100-240VAC~ 50/60Hz power supply. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MP5W Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5W-41 |
Autonics MP5W-41 Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | Relay (H, GO, L) |
| Measurement range | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : 0.0005Hz to 50kHzΓΒ·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time rangeΓΒ·Operation mode F11, F12, F13, F16 : 0 to 99999ΓΒ·Operation mode F14, F15 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ΓΒ±10% 80mA |
| Input frequency | ΓΒ·Solid state input 1: max. 50kHz (pulse width: min. 10Γ£Ε½Β²)ΓΒ·Solid state input 2: max. 5kHz (pulse width: min. 100Γ£Ε½Β²)Γ’β¬Β»For F7, F8, F9, F10 operation mode, max. 1kHz (pulse width: min. 500Γ£Ε½Β²)ΓΒ·Contact input: max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : F.S.ΓΒ±0.05%rdgΓΒ±1-digitΓΒ·Operation mode F3, F4, F5, F6 : F.S.ΓΒ±0.01%rdgΓΒ±1-digit |
| Prescale function | Direct input method (0.0001Γβ10@(^-9) to 9.9999Γβ10@(^9)) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 334g (approx. 210g) |
The Autonics designed the MP5W-41 for engineers who demand accuracy and versatility in High Performance Digital Pulse Meters. It features a clear 5-digit 7-segment LED display with 14mm character height, offering excellent visibility in low-light panels. The meter supports 16 measurement modesβincluding frequency, revolutions, speed, ratio, and accumulationβproviding flexible performance for dynamic industrial requirements. It operates on a stable 100β240VAC 50/60Hz power supply and accepts both voltage input (PNP) and no-voltage input (NPN) signals, ensuring compatibility with diverse sensor types. Relay-based main outputs (H, GO, L) allow easy comparative processing in high-speed automation tasks.
With a wide display range of -19999 to 99999 and measurement accuracy up to Β±0.01% of full scale, the MP5W-41 ensures precision you can rely on. It supports high-frequency signal processingβup to 50kHz for solid-state input 1βwhile offering a prescale function to match specific signal scaling needs. Its IP54-rated front panel withstands dusty environments, while the unitβs ambient temperature range (-10Β°C to 50Β°C) and external power support (12VDC Β±10%) make it suitable for harsh industrial settings. This robust performance makes it ideal for both new installations and retrofitting into legacy panels with minimal modification.
The Autonics MP5W-41 is a trusted solution across industries such as packaging, materials handling, and assembly automation. It is commonly deployed for machine cycle tracking, conveyor pulse monitoring, and speed detection in rotating equipment. Maintenance teams appreciate its consistent feedback, while system integrators value the reliability of its relay outputs. Whether you're optimizing a production line or teaching students how to configure pulse counters, this digital panel meter offers dependable accuracy with simplified wiring and setup. For complete technical documentation, visit the official Autonics Sensors & Controllers page or check the product category at Autonics Panel Meters.
