Autonics MP5W-21 Relay Digital Panel Meter
MP5W-21 is an Autonics Relay Digital Panel Meter with 5-digit LED display supporting multiple industrial measurement operation modes functions. Manufactured by Autonics, this meter belongs to the Autonics Digital Panel Meter category within the MP5W Series, providing -19999 to 99999 display range, 14mm character height, 5-digit 7-segment LED display, and support for 16 operation modes including frequency, speed, time, and counting measurements.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5W-21 |
Autonics MP5W-21 Relay Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| Output_Main Output(Comparative Value) | Relay (H, GO, L) |
| Measurement range | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : 0.0005Hz to 50kHzΓΒ·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time rangeΓΒ·Operation mode F11, F12, F13, F16 : 0 to 99999ΓΒ·Operation mode F14, F15 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ΓΒ±10% 80mA |
| Input frequency | ΓΒ·Solid state input 1: max. 50kHz (pulse width: min. 10Γ£Ε½Β²)ΓΒ·Solid state input 2: max. 5kHz (pulse width: min. 100Γ£Ε½Β²)Γ’β¬Β»For F7, F8, F9, F10 operation mode, max. 1kHz (pulse width: min. 500Γ£Ε½Β²)ΓΒ·Contact input: max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ΓΒ·Operation mode F1, F2, F7, F8, F9, F10 : F.S.ΓΒ±0.05%rdgΓΒ±1-digitΓΒ·Operation mode F3, F4, F5, F6 : F.S.ΓΒ±0.01%rdgΓΒ±1-digit |
| Prescale function | Direct input method (0.0001Γβ10@(^-9) to 9.9999Γβ10@(^9)) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 334g (approx. 210g) |
The MP5W-21 Autonics Relay Digital Panel Meter is designed for multi-function signal indication in industrial automation systems. This MP5W-21 Autonics Relay Digital Panel Meter uses a 5-digit 7-segment LED display with a -19999 to 99999 display range and 14mm character height. It belongs to the MP5W Series and is used where flexible measurement and relay-based control are required.
In industrial environments, the MP5W-21 Autonics Relay Digital Panel Meter is commonly installed in conveyors, packaging machines, automation panels, and assembly lines. Its multiple operation modes allow monitoring of frequency, speed, cycle, time, ratio, and counting values, supporting stable process control and reliable machine operation across industrial automation systems.
The MP5W-21 Digital Panel Meter delivers dependable visual indication and relay output handling for industrial control panels. As part of the MP5W Series, it reflects Autonics manufacturing reliability and suitability for continuous industrial use. This Autonics Relay Digital Panel Meter remains appropriate for applications requiring accurate multi-parameter monitoring and consistent relay-based signaling.
