Autonics MP5S-4N Digital Panel Meter
The Autonics MP5S-4N Digital Panel Meter offers 5-digit 7-segment LED display method, 8mm character height, -19999 to 99999 display range, 100-240VAC~ 50/60Hz power supply. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MP5S Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5S-4N |
Autonics MP5S-4N Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 8mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | Indicator |
| Measurement range | ·Operation mode F1, F2, F7, F8, F9, F10 : 0.0005Hz to 50kHz·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time range·Operation mode F11, F12, F13, F16 : 0 to 99999·Operation mode F14, F15 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ±10% 80mA |
| Input frequency | ·Solid state input 1: max. 50kHz (pulse width: min. 10㎲)·Solid state input 2: max. 5kHz (pulse width: min. 100㎲)※For F7, F8, F9, F10 operation mode, max. 1kHz (pulse width: min. 500㎲)·Contact input: max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ·Operation mode F1, F2, F7, F8, F9, F10 : F.S.±0.05%rdg±1-digit·Operation mode F3, F4, F5, F6 : F.S.±0.01%rdg±1-digit |
| Prescale function | Direct input method (0.0001×10@(^-9) to 9.9999×10@(^9)) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP54 (front part, IEC standard) |
| Weight | Approx. 191g (approx. 132g) |
The Autonics MP5S-4N features a 5-digit LED display with 8mm characters, covering a range from -19999 to 99999. It supports 16 operation modes including frequency, revolutions, cycle, time, and ratio. Powered by 100–240VAC or optional 12VDC, it delivers high accuracy of ±0.01% F.S. with prescale adjustment. Input flexibility includes PNP/NPN voltage inputs handling signals up to 50kHz, making it a reliable measurement tool for demanding automation panels.
Built for industrial reliability, the Autonics MP5S-4N Digital Panel Meter combines compact design with advanced functions. Its 16 measurement modes handle speed, frequency, and pulse counting, while the LED display ensures clear readings. With IP54 front protection, it withstands dust and moisture, operating efficiently from -10°C to 50°C. Engineers trust its ±0.01% accuracy, versatile PNP/NPN inputs, and stable 100–240VAC power supply for long-term use in automation systems.
Engineered for practical use, the Autonics MP5S-4N provides a bright 5-digit LED display and wide input capability. It adapts to 16 modes, from frequency measurement to length and ratio calculations. Designed for efficiency, it runs on 100–240VAC with external 12VDC option, and accepts PNP/NPN pulse inputs up to 50kHz. Its prescale function supports calibration, while the IP54-rated front panel ensures durability in workshop and factory environments.
The MP5S-4N Digital Panel Meter is widely used across industries such as packaging, textile, bottling, and assembly lines where real-time monitoring is critical. Engineers rely on it to track motor speed, measure belt cycles, calculate machine uptime, and monitor encoder pulse signals. Its compact size and lightweight design make installation easy in space-constrained panels. Maintenance teams value its clear display and precise outputs, while automation specialists integrate its relay output for alarms and process control. Even engineering students benefit from its simple, practical design when learning automation measurement systems. With its balance of accuracy, durability, and multi-functionality, the Autonics MP5S-4N proves itself as a dependable choice for industrial measurement needs in India and globally.
