Autonics MP5M-42 Digital Panel Meter
The Autonics MP5M-42 Digital Panel Meter offers 5-digit 7-segment LED display method, 8mm character height, -19999 to 99999 display range, 14 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MP5M Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5M-42 |
Autonics MP5M-42 Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 8mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 14 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | Relay (H, L)+NPN open collector |
| Measurement range | ΓΒ·Operation mode F1, F2, F7, F8 : 0.0005Hz to 50kHzΓΒ·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time rangeΓΒ·Operation mode F9, F10, F11, F14 : 0 to 99999ΓΒ·Operation mode F12, F13 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ΓΒ±10% 80mA |
| Input frequency | ΓΒ·Solid state input 1: max. 50kHz (pulse width: min. 10Γ£Ε½Β²)ΓΒ· Solid state input 2: max. 5kHz (pulse width: min. 100Γ£Ε½Β²)Γ’β¬Β»For F7, F8 operation mode, max. 1kHz (pulse width: min. 500Γ£Ε½Β²)ΓΒ·Contact input: Max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ΓΒ·Operation mode F1, F2, F7, F8 : F.S.ΓΒ±0.05%rdgΓΒ±1-digitΓΒ·Operation mode F3, F4, F5, F6 : F.S.ΓΒ±0.01%rdgΓΒ±1-digit |
| Prescale function | Direct input method (0.0001Γβ10@(^-9) to 9.9999Γβ10@(^9)) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 265g (approx. 190g) |
The Autonics MP5M-42 belongs to the advanced High Performance Digital Pulse Meters series, offering 14 operation modes such as frequency, revolutions, cycle, ratio, and length measurement. It features a 5-digit 7-segment LED display with 8mm character height and a wide display range of -19999 to 99999, ensuring clear visibility and high-resolution monitoring in control panels.
Engineered for versatility, the MP5M-42 Digital Panel Meter supports voltage input (PNP) and no-voltage input (NPN), with solid-state input frequencies up to 50kHz. Its measurement accuracy reaches Β±0.05% to Β±0.01% F.S. depending on the mode, making it highly reliable for high-speed industrial applications. The unit also integrates a prescale function, allowing engineers to configure custom scaling for RPM, flow, or length-based processes.
Powered by 100β240VAC 50/60Hz, the device includes both relay (H/L) and NPN open collector outputs for signaling, along with a 12VDC external power supply to support connected sensors. Designed to perform under tough environments, it withstands ambient temperatures from -10Β°C to 50Β°C and up to 85% RH. Compact at 265g, the MP5M-42 fits easily into control enclosures without compromising performance or durability.
Built for long-term reliability, this High Performance Digital Pulse Meter is trusted in industries such as packaging, power distribution, automotive, and electronics manufacturing. With its compact size, programmable flexibility, and robust safety features, the MP5M-42 helps engineers and technicians ensure precise control, optimized uptime, and reduced risk in modern automation.
For complete details, visit the Autonics Sensors & Controllers page or check other models in the Autonics Digital Panel Meters range.
