Autonics MP5M-41 Digital Panel Meter
The Autonics MP5M-41 Digital Panel Meter offers 5-digit 7-segment LED display method, 8mm character height, -19999 to 99999 display range, 14 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics MP5M Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MP5M-41 |
Autonics MP5M-41 Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 5-digit 7-segment LED |
| Character height | 8mm |
| Max. display Range | -19999 to 99999 |
| Measurement | 14 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Power supply | 100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) | Relay (H)+NPN open collector |
| Measurement range | ΓΒ·Operation mode F1, F2, F7, F8 : 0.0005Hz to 50kHzΓΒ·Operation mode F3, F4, F5, F6 : 0.01 to max. of each time rangeΓΒ·Operation mode F9, F10, F11, F14 : 0 to 99999ΓΒ·Operation mode F12, F13 : -19999 to 99999 |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| External Power Supply | Max. 12VDC @(=) ΓΒ±10% 80mA |
| Input frequency | ΓΒ·Solid state input 1: max. 50kHz (pulse width: min. 10Γ£Ε½Β²)ΓΒ· Solid state input 2: max. 5kHz (pulse width: min. 100Γ£Ε½Β²)Γ’β¬Β»For F7, F8 operation mode, max. 1kHz (pulse width: min. 500Γ£Ε½Β²)ΓΒ·Contact input: Max. 45Hz (pulse width: min. 11ms) |
| Measurement accuracy | ΓΒ·Operation mode F1, F2, F7, F8 : F.S.ΓΒ±0.05%rdgΓΒ±1-digitΓΒ·Operation mode F3, F4, F5, F6 : F.S.ΓΒ±0.01%rdgΓΒ±1-digit |
| Prescale function | Direct input method (0.0001Γβ10@(^-9) to 9.9999Γβ10@(^9)) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 256g (approx. 181g) |
The Autonics MP5M-41 Digital Panel Meter delivers accurate and versatile pulse measurement within the reliable MP5M Series. Featuring a 5-digit LED display with a -19999 to 99999 range, it supports various operation modes such as frequency, revolution, cycle, and time measurement. Designed to operate with 100β240VAC 50/60Hz power, it offers both relay and NPN open collector outputs for flexible system integration. With Β±0.05% full-scale accuracy in high-frequency modes and a fast input capability of up to 50kHz, the MP5M-41 ensures consistent and reliable readings across diverse automation applications.
In machine speed monitoring, conveyor control, and production line synchronization, this digital pulse meter provides real-time display and control of pulse signals. It supports prescale functions for ratio and interval calculations, enabling engineers to analyze performance parameters accurately. The MP5M-41 is widely used in industrial machinery, packaging systems, and process control applications where high-speed and precision measurement are essential. With a robust housing, excellent electrical isolation, and a measurement accuracy of Β±0.01% to Β±0.05% depending on mode, it ensures operational stability even in dynamic industrial environments across India.
Manufactured by Autonics Corporation, a globally recognized leader in industrial sensors and control instruments, the MP5M-41 represents the brandβs dedication to accuracy and durability. Built under ISO-certified manufacturing standards, it maintains stable operation across temperature ranges from -10Β°C to 50Β°C and relative humidity up to 85%. Trusted by automation professionals, OEMs, and engineers worldwide, Autonics pulse meters are known for their long-term reliability and ease of use. The companyβs extensive distribution and service network across India ensure reliable support and availability of replacement components.
Within the Autonics MP5M Series, several models provide distinct output configurations to match specific application needs. The Autonics MP5M-42 Digital Pulse Meter offers the same high-speed pulse measurement capabilities as the MP5M-41 but includes enhanced functionality with a slightly heavier build of approximately 265g (approx. 190g). Both models share the same 5-digit LED display, 100β240VAC power range, and multi-mode operation, ensuring seamless integration into a variety of industrial automation systems for monitoring frequency, speed, and process metrics.
In summary, the Autonics MP5M-41 Digital Pulse Meter from the MP5M Series offers a reliable, high-performance solution for frequency, speed, and time measurement in industrial automation environments. With features like Β±0.05% accuracy, relay + NPN outputs, and a wide 50kHz input frequency range, it ensures stable performance in demanding control systems. Backed by Autonics Corporationβs reputation for quality and engineering precision, the MP5M-41 remains a trusted choice among engineers and OEMs across India seeking dependable pulse monitoring and display solutions.
Autonics MP5M-41 People Also Asked Questions
What are the main features of the Autonics MP5M-41 Digital Panel Meter?
The Autonics MP5M-41 Digital Panel Meter is a high-performance pulse meter designed for versatile measurement applications. It features a 5-digit 7-segment LED display with an 8mm character height, ensuring excellent visibility. The device supports 14 operation modes, including frequency, speed, revolutions, time, ratio, length, and cycle measurement, offering flexibility for diverse industrial uses. Operating on a 100β240VAC power supply, it provides both relay (H) and NPN open collector outputs, making it suitable for process control and monitoring tasks.
What applications are suitable for the Autonics MP5M-41 Digital Panel Meter?
The Autonics MP5M-41 is ideal for industrial automation, machine speed monitoring, production line measurement, and rotary equipment testing. With its wide measurement range up to 50kHz and multiple input types (PNP and NPN), itβs commonly used in motors, conveyor systems, textile machinery, and packaging equipment. The meterβs prescale function allows easy scaling of measurement values, making it practical for systems requiring frequency, speed, or time-based control outputs.
How reliable is the Autonics MP5M-41 for industrial environments?
Built for stability and precision, the Autonics MP5M-41 Digital Panel Meter ensures measurement accuracy up to Β±0.05% F.S. depending on the operation mode. It maintains dependable performance under ambient temperatures from -10Β°C to 50Β°C and humidity levels between 35β85% RH. The deviceβs robust design, IP-rated protection, and 256g build make it durable for continuous use in factory automation, process monitoring, and motion control applications, where long-term accuracy and reliability are essential.
