Autonics M4NN-DV-1N Digital Panel Meter
The Autonics M4NN-DV-1N Digital Panel Meter offers 4-digit 7-segment LED display method, 11mm character height, -1999 to 9999 display range, DC voltage measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics M4NN Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | M4NN-DV-1N |
Autonics M4NN-DV-1N Digital Panel Meter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Character height | 11mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | -600-600V, -200-200V, -100-100V, -20-20V, -10-10V, -2-2V, -1-1V, -200-200mV |
| Power supply | 5-24VDC @(=) |
| Output_Main Output(Comparative Value) | Indicator |
| Display accuracy | Γ’β¬Β’23Γ’βΖΓΒ±5Γ’βΖ - ΓΒ±0.1% F.S. ΓΒ±2-digitΓ’β¬Β’-10 to 50Γ’βΖ - ΓΒ±0.5% F.S. ΓΒ±3-digit |
| A/D conversion method | Practical oversampling using successive approximation ADC |
| Sampling cycle | 50ms (resolution 1/12,000) |
| Power Factor Display | Power Factor Display |
| Max. allowable input | -110 to 110% of the rated measurement input range(when not using minus input: -10 to 110%) |
| Display cycle | 0.1 to 5.0 sec (selectable by 0.1 sec) |
| Environment_Ambient temperature | -10 to 50Γ’βΖ, storage: -20 to 60Γ’βΖ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure | IP53 (front part, IEC standard) |
| Weight | Approx. 83.6g(approx. 46.8g) |
The Autonics M4NN-DV-1N Digital Panel Meter is part of the reliable M4NN Series, known for its stable measurement accuracy and durable design for industrial applications. It offers a -1999 to 9999 display range, Β±0.1% full-scale accuracy at 23Β°C, and operates on a 5β24VDC power supply. With a 50ms sampling cycle and practical oversampling ADC conversion, the M4NN-DV-1N ensures precise readings for DC voltage measurement across a variety of input levels. Its 4-digit LED display with adjustable cycle time (0.1β5 seconds) allows clear, customizable data visualization, ideal for control panels and electrical testing setups.
In factory automation, power distribution, and control cabinet installations, this digital panel meter provides real-time voltage feedback and monitoring accuracy. It helps engineers measure input variations, maintain process consistency, and identify voltage fluctuations in production systems. The M4NN-DV-1N is particularly useful in laboratory test benches, energy management systems, and process equipment, where stable operation and fast sampling are essential. With its compact structure and high visibility, this model enhances efficiency in industrial automation across Indiaβs manufacturing, testing, and monitoring applications.
Manufactured by Autonics Corporation, a global leader in industrial automation instruments, the M4NN-DV-1N reflects the brandβs strong focus on reliability and measurement precision. Built under ISO-certified quality systems, it offers double or reinforced insulation between measurement and power parts for operator safety. Engineers and OEMs trust Autonics for dependable performance, consistent accuracy, and simple panel integration. With widespread availability and technical support in India, Autonics continues to provide reliable digital instrumentation solutions for control and monitoring needs.
Within the Autonics M4NN Series, users can select models designed for specific measurement and output preferences. The Autonics M4NN-DA-1N Digital Panel Meter offers similar design and accuracy but supports analog output for integration with external control systems. In comparison, the M4NN-DV-1N provides a DC voltage input display with comparative indicator output and weighs approximately 83.6g (approx. 46.8g). Both variants share identical front IP53 protection, 5β24VDC operation, and compact housing, ensuring compatibility and consistency across industrial control applications.
In summary, the Autonics M4NN-DV-1N Digital Panel Meter from the M4NN Series is an efficient and accurate measuring instrument for industrial automation in India. With its fast response time, wide input range, and bright LED display, it ensures stable voltage monitoring and control in demanding electrical environments. Backed by Autonics Corporationβs proven expertise and ISO-compliant manufacturing, the M4NN-DV-1N remains a trusted choice for professionals requiring precision, reliability, and long-term measurement stability.
Autonics M4NN-DV-1N People Also Asked Questions
What are the main features of the Autonics M4NN-DV-1N Digital Panel Meter?
The Autonics M4NN-DV-1N Digital Panel Meter is a high-precision measuring instrument featuring a 4-digit 7-segment LED display with an 11mm character height for enhanced readability. It supports a wide input range from -200mV to Β±600V, making it ideal for various DC voltage applications. With an impressive sampling cycle of 50ms and A/D conversion using a successive approximation ADC, it ensures rapid and accurate readings. Operating on 5β24VDC, the meter provides indicator output for comparative value monitoring in automation systems.
Where can the Autonics M4NN-DV-1N Digital Panel Meter be used effectively?
The Autonics M4NN-DV-1N is designed for versatile use in industrial automation, testing equipment, laboratory voltage measurement, and process control panels. Its ability to handle multiple input ranges allows flexible use across various voltage monitoring systems. With features like a selectable display cycle (0.1β5.0 seconds) and high-resolution 1/12,000 sampling, itβs ideal for precision applications in manufacturing, electrical panels, and R&D environments that require reliable DC voltage monitoring.
How reliable is the Autonics M4NN-DV-1N in industrial conditions?
The Autonics M4NN-DV-1N Digital Panel Meter is engineered for durability with double or reinforced insulation (1kV dielectric strength) and IP53 front protection against dust and moisture. It operates efficiently between -10Β°C to 50Β°C and tolerates up to 110% of the rated input range, ensuring safe and stable performance. Its lightweight 83.6g design and strong build make it suitable for continuous operation in industrial control cabinets, production machinery, and electrical systems demanding high measurement accuracy and reliability.
