Autonics M4NN-AA-12 Digital Panel Meter
The Autonics M4NN-AA-12 Digital Panel Meter offers 4-digit 7-segment LED display method, 11mm character height, -1999 to 9999 display range, AC current, Frequency measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics M4NN Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | M4NN-AA-12 |
Autonics M4NN-AA-12 Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Character height | 11mm |
| Max. display Range | -1999 to 9999 |
| Measurement | AC current, Frequency |
| Input specification | 0-5A, 0-2.5A, 0-1A, 0-500mA, 0-250mA, 0-100mA, 0-50mA |
| AC Measurement | Average value(AVG) |
| Power supply | 5-24VDC @(=) |
| Output_Main Output(Comparative Value) | PNP open collector (OUT1, GO, OUT2) |
| Display accuracy | •23℃±5℃ - ±0.3% F.S. ±3-digit※For 5A terminal of M4NN-DA, AA Input, ±0.3% F.S. ±3-digit•-10 to 50℃ - ±0.5% F.S. ±3-digit / Frequency: ±0.5% F.S. ±3-digit※For 5A terminal of M4NN-DA, AA Input, ±1% F.S. ±3-digit |
| A/D conversion method | Practical oversampling using successive approximation ADC |
| Sampling cycle | 16.6ms (resolution 1/12,000) |
| Max. allowable input | Approx. 110% of the rated measurement input range |
| Display cycle | 0.1 to 5.0 sec (selectable by 0.1 sec) |
| Frequency measurement | Measurement range: 0.100 to 9999Hz(variable by decimal point position) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure | IP53 (front part, IEC standard) |
| Weight | Approx. 83.8g(approx. 46.9g) |
Talk to Our Engineer for Autonics Compact Digital Panel Meter with Inputs M4NN-AA-12 with exclusive offers. Core System Specifications of M4NN-AA-12 are an 4-digit 7-segment LED with 11mm character height, these displays support a maximum range of -1999 to 9999. Designed for AC current, Frequency measurement, they handle 0-5A, 0-2.5A, 0-1A, 0-500mA, 0-250mA, 0-100mA, 0-50mA inputs. The system supports AVG and RMS measurement methods and operates on 5-24VDC @(=) power. Outputs include PNP open collector (OUT1, GO, OUT2) and . The display accuracy is •23℃±5℃ - ±0.3% F.S. ±3-digit※For 5A terminal of M4NN-DA, AA Input, ±0.3% F.S. ±3-digit•-10 to 50℃ - ±0.5% F.S. ±3-digit / Frequency: ±0.5% F.S. ±3-digit※For 5A terminal of M4NN-DA, AA Input, ±1% F.S. ±3-digit. The Practical oversampling using successive approximation ADC ensures precise 16.6ms (resolution 1/12,000) sampling. Equipped with a , it is ideal for industrial automation applications. Get a quote today for Autonics Display Units with superior accuracy and performance. Don't Miss Out on a Quote for your requirement of Compact Digital Panel Meter with Inputs. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
