Autonics M4N-DI-1X Digital Panel Meter

Name: Autonics M4N-DI-1X
Brand: Autonics
SKU: M4N-DI-1X
Rating: 4 (4 reviews)

The Autonics M4N-DI-1X Digital Panel Meter offers 3Â½-digit 7-segment LED display method, 10mm character height, 0 to 1999 display range, Digital scaling measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics M4N Series.

Datasheet

Brand	Autonics
Product Type	Digital Panel Meter
Model Number	M4N-DI-1X

Autonics M4N-DI-1X Digital Panel Meter – Technical Specifications

Specification	Value
Display method	3Â½-digit 7-segment LED
Character height	10mm
Max. display Range	0 to 1999
Measurement	Digital scaling
Input specification	DC4-20mA(1-5VDC @(=))
Power supply	12-24VDC @(=)
Output_Main Output(Comparative Value)	Indicator
Display accuracy	F.S. 0.2% rdg Â±1-digit
Sampling cycle	300ms
Max. allowable input	150% of measurement input range
Environment_Ambient temperature	-10 to 50â„ƒ, storage: -20 to 60â„ƒ
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Weight	Approx. 44g

Talk to Our Engineer for Autonics Compact Digital Panel Meters M4N-DI-1X with exclusive offers. Core System Specifications of M4N-DI-1X are an 3Â½-digit 7-segment LED with 10mm character height, these displays support a maximum range of 0 to 1999. Designed for Digital scaling measurement, they handle DC4-20mA(1-5VDC @(=)) inputs. The system supports AVG and RMS measurement methods and operates on 12-24VDC @(=) power. Outputs include Indicator and . The display accuracy is F.S. 0.2% rdg Â±1-digit. The ensures precise 300ms sampling. Equipped with a , it is ideal for industrial automation applications. Get a quote today for Autonics Display Units with superior accuracy and performance. Don't Miss Out on a Quote for your requirement of Compact Digital Panel Meters. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
