Autonics M4M1P-DV-XX Digital Panel Meter
The Autonics M4M1P-DV-XX Digital Panel Meter offers 3½-digit 7-segment LED display method, 10mm character height, 0 to 1999 display range, DC voltage measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics M4W1P Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | M4M1P-DV-XX |
Autonics M4M1P-DV-XX Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 3½-digit 7-segment LED |
| Character height | 10mm |
| Max. display Range | 0 to 1999 |
| Measurement | DC voltage |
| Input specification | Option |
| Sampling cycle | 300ms |
| Max. allowable input | 150% for each input specification (at 400VAC:120%) |
| Power supply(Option) | 110/220VAC~ 50/60Hz |
| Output | Relay(HI) |
| Display accuracy_DC power | F.S. ±0.2% rdg ±1-digit |
| Environment_Ambient temperature | -10 to 50℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 290g |
Talk to Our Engineer for Autonics Digital Voltmeters M4M1P-DV-XX with exclusive offers. Core System Specifications of M4M1P-DV-XX are an 3½-digit 7-segment LED with 10mm character height, these displays support a maximum range of 0 to 1999. Designed for DC voltage measurement, they handle Option inputs. The system supports AVG and RMS measurement methods and operates on 110/220VAC~ 50/60Hz Power supply(Option). Outputs include Relay(HI) and -10 to 50℃, storage: -25 to 65℃Environment_Ambient temperature. The Environment_Ambient humidity is 35 to 85% RH, storage: 35 to 85% RH. The Approx. 290g Weight ensures precise 300ms sampling. Equipped with a 150% for each input specification (at 400VAC:120%), Max. allowable input for industrial automation applications. Get a quote today for Autonics Display Units with superior accuracy and performance. Don't Miss Out on a Quote for your requirement of Digital Voltmeters. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
