Autonics L2RR-L3GD - 22/25 mm Pilot Lights
L2RR-L3GD is an Autonics 22/25 mm Pilot Lights operating on 12-24VAC/DC with green lamp indication. Manufactured by Autonics, this model belongs to Autonics Control Switches and the L2RR Series for industrial automation in India. It features 12-24VAC/DC LED power supply, maximum 20mA current consumption, IP52 protection structure, green lamp marking, and approximately 7g housing weight.
| Brand | Autonics |
| Product Type | Control Switch |
| Model Number | L2RR-L3GD |
Autonics 22/25 mm Pilot Lights L2RR-L3GD Technical Specifications
| Specification | Value |
|---|---|
| LED block_Power supply | 12-24VAC~ 50/60Hz, 12-24VDC @(=) |
| LED block_Current consumption | Max. 20mA |
| Letter marking | Marking(Lamp) |
| Color | Green |
| Head type | Flat round(extended) |
| LED block type | Singular type |
| Environment_Ambient temperature | -15 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP52 |
| Weight_Housing | Approx. 7g |
| Weight_LED block_AC/DC voltage type | Approx. 11g |
| Weight_LED block_AC voltage type | Approx. 11g |
| Weight_Mounting hole_Γ22/25 | Approx. 15.5g |
TheL2RR-L3GD Autonics 22/25 mm Pilot Lights is designed for panel-mounted visual indication in industrial automation systems. The L2RR-L3GD operates on 12-24VAC/DC power supply with maximum 20mA current consumption and maintains IP52 protection. As part of the L2RR Series, L2RR-L3GD supports structured status signaling in control panels across India.
In conveyor systems, packaging lines, assembly units, and machine control boards, L2RR-L3GD Autonics 22/25 mm Pilot Lights provides clear visual confirmation of operational states. The green lamp marking indicates normal running conditions. Its defined voltage range ensures stable illumination performance within industrial electrical panels.
Autonics L2RR-L3GD within Autonics 22/25 mm Pilot Lights category delivers specified electrical characteristics and enclosure protection for automation environments. With controlled LED consumption and IP52 housing structure, L2RR-L3GD aligns with industrial panel integration requirements. Autonics maintains consistent manufacturing standards, and L2RR-L3GD under the L2RR Series remains suitable for dependable visual indication applications.
