Autonics FX6M-2P4 Counter
The Autonics FX6M-2P4 Counter offers 1, 30, 2k, 5k [cps] counting speed, 100-240VAC~ 50/60Hz power supply, Terminal block, 2-stage preset control output. Manufactured by Autonics under the Autonics Counters category, this model belongs to the Autonics FXM Series.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | FX6M-2P4 |
Autonics FX6M-2P4 Counter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 6-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 2k, 5k [cps] |
| Min. signal Width | 20ms |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) ±10% 50mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Output Operation | POWER ON DELAY, FLICKER |
| Time operation | POWER ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.1 sec to 99999.9 sec, 1 sec to 999999 sec, 0.01 sec to 99 min 59.99 sec, 0.1 sec to 999 min 59.9 sec, 0.1 min to 99999.9 min, 1 sec to 99 hour 59 min 59 sec, 1 min to 9999 hour 59 min, 0.1 hour to 99999.9 hour |
| Control output_Type | 2-stage preset |
| Control output_Relay | SPDT (1c): 2 |
| Control output_NPN open collector | 2 |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP20(front panel) |
| Weight | Approx. 265g (approx. 200g) |
Obtain a Quote for Standard Digital Counter/Timers FX6M-2P4 at economical prices. Specifications Overview for FX6M-2P4 reveals counting the speed of 1, 30, 2k, 5k [cps], ensuring accurate data processing. With a minimum signal width of 20ms for counting value signals, they provide dependable performance in high-speed operations. Operating on a 100-240VAC~ 50/60Hz power supply, the sensors feature memory protection with a non-volatile semiconductor memory type, offering a retention period of approximately Approx. 10 years. Built to withstand challenging environments, they operate efficiently in a wide ambient temperature range -10 to 55℃, storage: -25 to 65℃ and come with a robust protection structure IP20(front panel) to ensure durability. Compact and lightweight Approx. 265g (approx. 200g), these sensors are easy to install and integrate into existing systems. Take the First Step with a Quote for your requirement of Standard Digital Counter/Timers. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
