Autonics FX4Y-I2 Counter
The Autonics FX4Y-I2 Counter offers 1, 30, 2k, 5k [cps] counting speed, 24VAC~ 50/60Hz, 24-48VDC power supply, Terminal block, Indicator control output. Manufactured by Autonics under the Autonics Counters category, this model belongs to the Autonics FXY Series.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | FX4Y-I2 |
Autonics FX4Y-I2 Counter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 2k, 5k [cps] |
| Min. signal Width | 20ms |
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| External Power Supply | Max. 12VDC @(=) Β±10% 50mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Time operation | POWER ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 99 hour 59 min, 0.1 hour to 999.9 hour, 1 hour to 9999 hour |
| Control output_Type | Indicator |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP40(front panel) |
| Weight | Approx. 175g (approx. 120g) |
The Autonics FX4Y-I2 Digital Counter/Timer Indicator features a 4-digit 7-segment LED display that provides clear visibility in control panels. It supports counting speeds up to 5k cps with a minimum signal width of 20ms, ensuring accurate detection even in high-speed production environments. Powered by 24VAC 50/60Hz or 24β48VDC, this model offers installation flexibility across diverse automation systems.
Engineers value the FX4Y-I2 for its versatile input compatibility, supporting both PNP and NPN signal types. Its wide time setting rangeβfrom 0.01 seconds to 9999 hoursβaccommodates short cycle control as well as long-duration operations. With count up, count down, and up/down modes, it adapts to different process requirements. Memory protection ensures settings are preserved for up to 10 years, while the IP40-rated front panel and β10Β°C to 55Β°C operating range guarantee dependable performance in factory environments.
Applications of the Autonics FX4Y-I2 Counter include bottling machines, packaging lines, labeling systems, and cycle monitoring. Maintenance teams use it for retrofitting older machines, benefiting from its simple terminal block wiring and lightweight 175g build. Operators appreciate the intuitive display for real-time monitoring and troubleshooting during production. For more solutions, visit the Autonics Sensors & Controllers page or see the full range of Autonics Counters for additional models.
