Autonics FX4M-1P4 Standard Digital Counter/Timers
FX4M-1P4 Autonics Standard Digital Counter/Timers provides a 4-digit LED display, selectable counting speeds, and IP20 front panel protection rated. Manufactured by Autonics, this Autonics Counter from the FXY Series supports count up and down operation, 20ms signal width, 100β240VAC power supply, terminal block wiring, and one-stage preset control output.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | FX4M-1P4 |
Autonics FX4M-1P4 Standard Digital Counter/Timers β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 2k, 5k [cps] |
| Min. signal Width | 20ms |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) Β±10% 50mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Output Operation | POWER ON DELAY, FLICKER |
| Time operation | POWER ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 99 hour 59 min, 0.1 hour to 999.9 hour, 1 hour to 9999 hour |
| Control output_Type | 1-stage preset |
| Control output_Relay | SPDT (1c): 1 |
| Control output_NPN open collector | 1 |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP20(front panel) |
| Weight | Approx. 245g (approx. 180g) |
The Autonics FX4M-1P4 Standard Digital Counter/Timers is used for counting and timing control in industrial automation systems. This model provides a 4-digit 7-segment LED display, counting speeds up to 5k cps, and a stable preset output for control functions. Operating on 100β240VAC, it belongs to the FXY Series and is installed in industrial control panels.
In industrial automation environments, FX4M-1P4 Autonics Standard Digital Counter/Timers is applied in conveyors, packaging machines, assembly lines, and automated process equipment. It supports reliable event counting and timing logic with consistent output behavior. The terminal block connection and IP20 front structure allow dependable operation within protected electrical enclosures.
FX4M-1P4 remains a reliable counter solution within the FXY Series for industrial automation use. With its 4-digit display, defined operating modes, and stable power specifications, it supports consistent long-term operation. Autonics manufacturing standards and controlled specifications make this model suitable for engineers requiring dependable counting and timing performance.
