Autonics FS4E-1P4 8-Pin Plug Type Digital Timer
The FS4E-1P4 is an Autonics 8-Pin Plug Type Digital Timer supporting count up down operation with 100β240VAC supply input. Manufactured by Autonics, this timer is part of Autonics Timers and the FSE Series, featuring POWER ON DELAY and FLICKER INTERVAL output operation, POWER ON START timing, an 8-pin plug terminal, and wide digital setting ranges.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | FS4E-1P4 |
Autonics FS4E-1P4 8-Pin Plug Type Digital Timer β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Operation method | Count up, Count down |
| Output Operation | POWER ON DELAY, FLICKER |
| Time operation | POWER ON START |
| Terminal | 8-pin plug |
| Power supply | 100-240VAC~ 50/60Hz |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Min. signal Width | RESET, INHIBIT: approx. 20ms |
| Memory Protection | Approx. 10 years |
| Control output_Relay | SPDT (1c): 1 |
| Protection structure | IP20(front panel) |
| External Power Supply | Max. 12VDC Β±10% 50mA |
| Control output_Type | 1-stage preset |
| Setting range | 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 99 hour 59 min, 0.1 hour to 999.9 hour, 1 hour to 9999 hour |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 130g (approx. 90g) |
The Autonics FS4E-1P4 8-Pin Plug Type Digital Timers model is designed for accurate digital time control in industrial automation systems. This Autonics timer supports count up and count down operation, POWER ON DELAY and FLICKER INTERVAL modes, and operates on a 100β240VAC power supply. It belongs to the FSE Series and is used in panel-mounted timing applications.
In industrial automation environments, the FS4E-1P4 is applied in conveyors, packaging equipment, automated assembly lines, and sequential process control panels. Digital time setting allows precise adjustment across seconds, minutes, and hours. Stable output operation helps maintain consistent machine sequencing, reducing timing errors during repetitive production cycles.
The FS4E-1P4 timer reflects Autonics reliability in digital timing control. With an 8-pin plug structure, wide selectable time ranges, and dependable AC power compatibility, it integrates easily into industrial panels. As part of the FSE Series, this model is suitable for long-term industrial use where accurate timing and predictable digital control are required.
