Autonics FM4M-1P4 Counter
The Autonics FM4M-1P4 Counter offers 1, 30, 300, 2k, 5k [cps] counting speed, 100-240VAC~ 50/60Hz power supply, Terminal block, 1-stage preset control output. Manufactured by Autonics under the Autonics Counters category, this model belongs to the Autonics FM Series.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | FM4M-1P4 |
Autonics FM4M-1P4 Counter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 300, 2k, 5k [cps] |
| Min. signal Width | 20ms |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) ±10% 50mA |
| Operation method | Count up, Count down, Count up/down |
| Terminal | Terminal block |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Control output_Type | 1-stage preset |
| Control output_Relay | SPDT (1c): 1 |
| Control output_NPN open collector | 1 |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP20(front panel) |
| Weight | Approx. 245g (approx. 180g) |
Send Your Inquiry for Digital Measure Counters FM4M-1P4 with cost-effective solutions. Essential Technical Specs of FM4M-1P4 are counting the speed of 1, 30, 300, 2k, 5k [cps], ensuring accurate data processing. With a minimum signal width of 20ms for counting value signals, they provide dependable performance in high-speed operations. Operating on a 100-240VAC~ 50/60Hz power supply, the sensors feature memory protection with a non-volatile semiconductor memory type, offering a retention period of approximately . Built to withstand challenging environments, they operate efficiently in a wide ambient temperature range -10 to 55℃, storage: -25 to 65℃ and come with a robust protection structure IP20(front panel) to ensure durability. Compact and lightweight Approx. 245g (approx. 180g), these sensors are easy to install and integrate into existing systems. Capture the Best Deal with a Quote for your requirement of Digital Measure Counters. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
