Autonics ERB-A-26S-06/08 Rotary Encoder
The Autonics ERB-A-26S-06/08 Rotary Encoder offers control output, , allowable frequency, diameter. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the ERB Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | ERB-A-26S-06/08 |
Autonics ERB-A-26S-06/08 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Max. allowable revolution | 15000rpm |
| Connection method | Set screw |
| Material | Aluminum(AL 7075-T6), Alumite surface |
| Max. torque | 3.0N.m(30.42kgf.cm) |
| Rated torque | 1.5N.m(15.21kgf.cm) |
| Mounting bolt | M4 |
| Mounting torque | 1.7N.m |
| Min. allowable misalignment | Ø5mm |
| Max. allowable misalignment | Ø12mm |
| Inner diameter of both ends | Ø6mm/Ø8mm |
| Torsional stiffness | 240 N·m/rad |
| Weight | Approx. 37.3g(approx. 36.7g) |
Ask for the Pricing of Flexible Shaft Couplings ERB-A-26S-06/08 at unbeatable prices. Detailed Specifications of ERB-A-26S-06/08 features Set screw connection method for reliable attachment in various industrial applications. Constructed from an Aluminum(AL 7075-T6), Alumite surface finish, it ensures durability and lightweight performance. The encoder's maximum torque is rated at 3.0N.m(30.42kgf.cm), while the rated torque is 1.5N.m(15.21kgf.cm), making it highly efficient for demanding operations. It uses M4 mounting bolts, designed to withstand a mounting torque of 1.7N.m for secure installation. The encoder supports a minimum allowable misalignment of Ø5mm and a maximum of Ø12mm. The inner diameter at both ends measures Ø6mm/Ø8mm, ensuring versatile compatibility. With a torsional stiffness of 240 N·m/rad, it delivers exceptional precision. Now's the Time to Secure a Quote for your requirement of Flexible Shaft Couplings. We're committed to offering more favorable pricing and more responsive support than other Traders.
