Autonics ENP-101R-360-N Single Turn Encoder
The ENP-101R-360-N is an Autonics Single Turn Encoder with 360P/R resolution and 12–24VDC supply and NPN open collector output. Manufactured by Autonics, this encoder under the Autonics Encoders range belongs to the ENP Series, supporting 3600 rpm maximum allowable revolution, IP50 protection structure, axial cable connection type, and approximate weight of 478 g.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | ENP-101R-360-N |
Autonics ENP-101R-360-N Single Turn Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Shaft outer diameter | Ø10mm |
| Max. response frequency | 20kHz |
| Max. allowable revolution | 3600rpm |
| Starting torque | Max. 500gf.cm(max. 0.049N.m) |
| Resolution | 360P/R |
| Control output | NPN open collector |
| Power supply | 12-24VDC |
| Connection type | Axial cable type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Fixing bracket, Coupling |
| Weight | Approx. 478g(approx. 400g) |
The ENP-101R-360-N Autonics Single Turn Encoder is a rotary position feedback device designed for industrial automation control systems. This model provides 360P/R resolution, operates on 12–24VDC power supply, and supports 3600 rpm allowable revolution using an NPN open collector control output. It belongs to the ENP Series and is used where defined single-turn position feedback is required in automation environments.
In industrial applications, the ENP-101R-360-N Autonics Single Turn Encoder is applied in conveyors, packaging machinery, automated assembly equipment, and material handling systems. Single-turn position output allows accurate angular position detection within one rotation. The axial cable connection and stable electrical output support consistent signal transmission in control panels and rotating machinery.
The ENP-101R-360-N from Autonics delivers reliable single-turn position feedback with clearly defined electrical and mechanical characteristics. As part of the ENP Series, it aligns with established Autonics encoder specifications used across industrial automation installations. This Autonics Single Turn Encoder is suitable for engineers requiring dependable position detection, stable output behavior, and compatibility with standard industrial control systems.
