Autonics ENHP-100-1-L-5 Rotary Encoder
The Autonics ENHP-100-1-L-5 Rotary Encoder offers Line Driver control output, D-SUB connector type, 10kHz allowable frequency, diameter. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the ENHP Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | ENHP-100-1-L-5 |
Autonics ENHP-100-1-L-5 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Max. response frequency | 10kHz |
| Max. allowable revolution | 200rpm(Normal), 600rpm(Peak) |
| Starting torque | Max. 1kgf.cm(max. 0.098N.m) |
| Resolution | 100P/R |
| Output phase | A, @(A^), B, @(B^) |
| Control output | Line Driver |
| Power supply | 5VDC |
| Connection type | D-SUB connector type |
| Click stopper position | Normal "H" |
| Protection structure | IP67 |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Weight | Approx. 730g |
IndMALL Automation Dealing offers Portable Handle Incremental Encoder ENHP-100-1-L-5 at unbeatable prices. The Main Technical Parameters of ENHP-100-1-L-5 are maximum response frequency of 10kHz and the maximum allowable revolution speed of 200rpm(Normal), 600rpm(Peak), ensuring smooth and reliable operation in demanding applications. It features a Line Driver control output, providing efficient and accurate signal transmission. Designed to operate with a power supply 5VDC, this encoder ensures stability and precision. The D-SUB connector type simplifies integration, making it suitable for various industrial systems. Built with an IP67 protection structure, it offers reliable resistance against dust for enhanced durability. The encoder is engineered to operate within an ambient temperature range of -10 to 70℃, storage: -25 to 85℃. It supports humidity levels of 35 to 85% RH, storage: 35 to 90% RH in storage. Take the First Step with a Quote for your requirement of Portable Handle Incremental Encoder. Choose us for unparalleled pricing and support over other Dealers & Distributors.
