Autonics ENH-25-1-T-24 Rotary Encoder
The Autonics ENH-25-1-T-24 Rotary Encoder offers Totem pole control output, Terminal block, 10kHz allowable frequency, diameter. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the ENH Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | ENH-25-1-T-24 |
Autonics ENH-25-1-T-24 Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Max. response frequency | 10kHz |
| Max. allowable revolution | 200rpm(Normal), 600rpm(Peak) |
| Starting torque | Max. 1kgf.cm(max. 0.098N.m) |
| Resolution | 25P/R |
| Output phase | A, B |
| Control output | Totem pole |
| Power supply | 12-24VDC |
| Connection type | Terminal block |
| Click stopper position | Normal "H" |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70β, storage: -25 to 85β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Weight | Approx. 330g(approx. 260g) |
Obtain a Quote for Manual Handle Incremental Encoder ENH-25-1-T-24 at economical prices. Specifications Overview for ENH-25-1-T-24 reveals maximum response frequency of 10kHz and the maximum allowable revolution speed of 200rpm(Normal), 600rpm(Peak), ensuring smooth and reliable operation in demanding applications. It features a Totem pole control output, providing efficient and accurate signal transmission. Designed to operate with a power supply 12-24VDC, this encoder ensures stability and precision. The Terminal block simplifies integration, making it suitable for various industrial systems. Built with an IP50 protection structure, it offers reliable resistance against dust for enhanced durability. The encoder is engineered to operate within an ambient temperature range of -10 to 70β, storage: -25 to 85β. It supports humidity levels of 35 to 85% RH, storage: 35 to 90% RH in storage. Take the First Step with a Quote for your requirement of Manual Handle Incremental Encoder. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
