Autonics ENC-1-3-V-5-C Rotary Encoder
The Autonics ENC-1-3-V-5-C Rotary Encoder offers Voltage control output, Axial cable connector type, 180kHz allowable frequency, 5VDC power supply. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the ENC Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | ENC-1-3-V-5-C |
Autonics ENC-1-3-V-5-C Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Max. response frequency | 180kHz |
| Max. allowable revolution | 5000rpm |
| Output phase | A, B |
| Control output | Voltage |
| Power supply | 5VDC |
| Connection type | Axial cable connector type |
| Wheel diameter | 250mm |
| Gear ratio | 4:1 |
| Number of pulses | 1 |
| Min. measurement unit | 1m |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70β, storage: -25 to 85β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Weight | Approx. 494g |
Obtain a Quote for Wheel Type Incremental Rotary Encoder ENC-1-3-V-5-C at economical prices. Specifications Overview for ENC-1-3-V-5-C reveals maximum response frequency of 180kHz and the maximum allowable revolution speed of 5000rpm, ensuring smooth and reliable operation in demanding applications. It features a Voltage control output, providing efficient and accurate signal transmission. Designed to operate with a power supply 5VDC, this encoder ensures stability and precision. The Axial cable connector type simplifies integration, making it suitable for various industrial systems. Built with an IP50 protection structure, it offers reliable resistance against dust for enhanced durability. The encoder is engineered to operate within an ambient temperature range of -10 to 70β, storage: -25 to 85β. It supports humidity levels of 35 to 85% RH, storage: 35 to 90% RH in storage. Take the First Step with a Quote for your requirement of Wheel Type Incremental Rotary Encoder. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
