Autonics E40H8-2500-6-L-5-C 40 mm Incremental Rotary Encoder
The E40H8-2500-6-L-5-C is a 40 mm incremental rotary encoder delivering 2500P/R resolution, 300kHz response, and 5000rpm operation industrial automation applications. Manufactured by Autonics, this Autonics 40 mm Incremental Rotary Encoder belongs to the Autonics Encoder category and the E40H Series, featuring Ø8mm shaft diameter, Line Driver output, 5VDC power supply, IP50 protection, A/B/Z output phases, radial cable connector type, and approximately 120g weight.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | E40H8-2500-6-L-5-C |
Autonics E40H8-2500-6-L-5-C 40 mm Incremental Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Shaft inner diameter | Ø8mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 50gf.cm(max. 0.0049N.m) |
| Resolution | 2500P/R |
| Output phase | A, @(A^), B, @(B^), Z, @(Z^) |
| Control output | Line Driver |
| Power supply | 5VDC |
| Connection type | Radial cable connector type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Bracket |
| Weight | Approx. 120g |
The Autonics E40H8-2500-6-L-5-C 40 mm Incremental Rotary Encoder is a defined feedback device used in industrial automation systems. The E40H8-2500-6-L-5-C encoder provides 2500P/R resolution, supports a maximum 300kHz response frequency, and operates up to 5000rpm. Powered by a 5VDC supply with Line Driver control output, it is part of the E40H Series applied across industrial environments in India.
The E40H8-2500-6-L-5-C encoder is used in conveyors, packaging equipment, automated assembly stations, and motion-controlled machinery. This rotary encoder E40H8-2500-6-L-5-C delivers stable differential pulse signals for precise speed and position monitoring, supporting reliable communication with PLCs and motion controllers. Its A, B, Z phase outputs help maintain consistent signal integrity in control panels.
The E40H8-2500-6-L-5-C rotary encoder combines controlled starting torque, IP50 protection structure, and radial cable connector wiring for enclosed industrial installations. This encoder E40H8-2500-6-L-5-C supports continuous-duty operation where accurate rotational feedback is required. As an Autonics 40 mm Incremental Rotary Encoder, it fits structured automation architectures requiring dependable and repeatable performance.
